H460 Best FPV TX Module for Wireless Audio Video Transmission

H460 Best FPV TX Module for Wireless Audio Video Transmission thumbnail-1
H460 Best FPV TX Module for Wireless Audio Video Transmission photo-1
US$ 1 - 42 MOQ: 10 Sets
Key Specifications
Get Latest Price
Type:
Helicopter
Power:
Battery
Material:
Plastic
Contact Supplier Request Quote Chat Now
Shenzhen Aoweishi Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Helicopter
Power Battery
Material Plastic
Plastic Type ABS
Scale 1:5
Radio Control Style RC Hobby
Place of Origin Guangdong, China
Brand Name Flysight
Model Number CM100T FPV TX Module

Specifications

CM100T remote control micro camera for rc planes
camera with transmitter&module
fpv hd camera for dji phantom quadcopter

Best FPV TX Module for Wireless Audio Video Transmission



This is kit comes with a mini fpv camera with a tiny  200mW 5.8Ghz wireless Transmitter for DJI phantom ,DJI quadcopter.  The entire kit (with camera/ transmitter) and wires weighs just 6g making this the ideal FPV camera TX combo, if you don't have any spare weight on your FPV platform.  Its best to power this setput with a 1S lipo battery.



H460 Best FPV TX Module for Wireless Audio Video Transmission



1) Super light and super mini camera: 9.5X9.5X12mm



2) 4Gram only of the combination of FPV Camera and 5.8G 200mW Transmitter



3) High definition micro CCTV camera,520TVL



4) 0.008lux,can view  clearly in almost complete darkness



5) Double lens-day&night offered .



H460 Best FPV TX Module for Wireless Audio Video Transmission

Mini FPV camera Specifications:

Model

CM100 1g very weightlight mini camera

Style

Ultra light mini FPV camera

Sensor

1/3CMOS

System

NTSC: 656x493 PAL: 768x576

Horizontal Resolution

520TVL

Excellent Low light performance

0.008Lux/F1.2

Lens and View Angle

0.5mm F2.0/55°

Camera dimensions

9.5x9.5x12mm

Power Supply

DC3.3-5V/70mA

Video output

1.0Vp-p/75ohm



Mini 5.8Ghz Transmitter specifications:

Model

M5802 wireless transmitter

Transmitter Frequency

5725-5865MHZ; 8Channel

Transmitting Power

23dBm/200mW

Frequency Control

Built-in Frequency and phase lock loop

AV input

Analog AV signal input

Power Supply Voltage

DC3.3V-5V(better not use 5V for long time)

Supply current

320mA

Dimension(L*W*H)

19x19x3mm



H460 Best FPV TX Module for Wireless Audio Video Transmission



H460 Best FPV TX Module for Wireless Audio Video TransmissionH460 Best FPV TX Module for Wireless Audio Video TransmissionH460 Best FPV TX Module for Wireless Audio Video TransmissionH460 Best FPV TX Module for Wireless Audio Video TransmissionH460 Best FPV TX Module for Wireless Audio Video Transmission

H460 Best FPV TX Module for Wireless Audio Video Transmission



Product Details:



H460 Best FPV TX Module for Wireless Audio Video Transmission



FPV Kit Contents:

  • 1x Micro FPV Camera
  • 1x Daylight Lens
  • 1x Night time Lens
  • 1x Micro 5.8Ghz Transmitter with built in antenna
  • 1x RCA Video Cable set
How to change the FPV transmitter channels?



The channels can be selected or changed on your transmitter module by soldering jumpers between the Channel 1, 2, and 3 pins and ground as described below.

  • Ch1 pin + Ch2 pin + Ch3 pin connect to ground (Channel 1 - 5.705 gHz)
  • Ch2 pin + Ch3 pin connect to ground (Channel 2 - 5.685 gHz)
  • Ch1 pin + Ch3 pin connect to ground (Channel 3 - 5.665 gHz)
  • Ch1 pin + Ch2 pin connect to ground (Channel 5 - 5.885 gHz)
  • Ch3 pin connect to ground (Channel 4 - 5.645 gHz)
  • Ch2 pin connect to ground (Channel 6 - 5.905 gHz)
  • Ch1 pin connect to ground (Channel 7 - 5.925 gHz)
  • DEFAULT - no connect to ground (Channel 8 - 5.945 gHz)
H460 Best FPV TX Module for Wireless Audio Video Transmission
  • Provide the best service as alibaba Gold Supplier.
  • Top Quality Parts and 1 year Warranties.
  • OEM&ODM service.
  • Sufficient Stock and Fast Delivery. And all our product will be strictly tested before delivery
  • Price Promise – factory price and the lowest shipping cost.
  • Not sell in China to avoid cross selling, protect customers benefits and sales channels.

  • Any of your idea on our product we can help you to design and put it into production.

  • High quality, fashion designs, reasonable&competitive price fast lead time.

Advantages:

1 Original products for our own brand Flysight, quality is warranty.

2 We aim to provide customers high quality products and services.

3 CE certification provided for our products model: TX58025, RC306,etc.

4 OEM &ODM orders are welcome!



Applications:



 H460 Best FPV TX Module for Wireless Audio Video Transmission



Factory show:

H460 Best FPV TX Module for Wireless Audio Video Transmission



H460 Best FPV TX Module for Wireless Audio Video Transmission
