B192 FlySight Radio Monitor For Tarot Iron Man 680 Aluminum Tubes Foldable Hexacopter Frame Kit

Specifications

FlySight Radio Monitor For Tarot Iron Man 680 Aluminum Tubes Foldable Hexacopter Frame Kit
Tarot 650
Foldable
Quadcopter
Fra

FlySight Radio Monitor For Tarot Iron Man 680 Aluminum Tubes Foldable Hexacopter Frame Kit

• 7" HD 1024*600 Screen
• Two screen options: Matte screen and Mirror/brilliant screen
• 5 modes support: Diversity/RX1/RX2/AV IN//HDMI mode
• No "blue screen" .
• Support Image Zoom Function;
• Support Fatshark Nextwave&Airwave TX without distorted picture;

• Support image rotation 180 degree;

• Built-in Dual Receiver Automatically for best reception Automatic Antenna Switching
• Dual buffered AV outputs
• Can receive 2 different channels at the same time
• Not affect by 2.4GHz R/C Radios
• Anti-black, anti-blue, anti-flash.
• AV Receiver with Diversity inputs,AV, HDMI
• Small, light weight, durable,stylish
• 32 Channels



Display Screen

Diagonal:    7 inch

Resolution: 1024X600

Contrast:    700:1

Luminance: 300cd/m^2



Wireless Receiving

Working frequency:

Sensitivity:      -90dBm±1dBm

Channel:          32Channel ( 4 Band X 8 Channel )

Antenna Port:   2 X SMA,50ohm

Diversity receiving: Antenna diversity

TV System: NTSC/PAL

Video output level: 1.0Vp-p Typ,75ohm

Audio output level:1.0Vp-p Typ,10Kohm



AV Port

RX1 AV OUT:      Video,Audio output

RX2 AV OUT:      Video,Audio output

DIV AV OUT:      Diversity receiving, Video,Audio output

AV IN:            Video,Stereo Audio input HDMI IN(A Type) Support

HDMI:            1.3 Digital Input, Support HDMI Audio in

Built-in Microphone:  8Ω/1W X 2



Power Supply

DC IN:  7~28V/ 2A

DC OUT: Output Voltage:DC IN or battery voltage

                Output Current: 1A

Battery:  11.1V/1000mAh(3 series LiPo cells)

Consumption: 12V input:7.8W Dimensions



Dimensions

Main Body:  183X126X19.5mm(not include sun shadow)

Battery:  105X87.5X6.7 mm(not include prominent part)



Weight

Main body:  350 g

Battery:   95 g



Tripod connector: General 1/4 "thread

Working Temperature: -10°C~+65°C





Main Body:

Battery installation:

Images:



Packing List;

1*RC801

1*sunshadow

2*antenna

1*battery

AV cable

DC input cable

DC output cable
