Help CenterG2718 High Quality Flysight Black Pearl RC801 Lite 1280*800 7 Inch HD Lcd Display Monitor Support HDMI 1.3 in
Related Products
-
G2717 1280*800 7 Inch HD Lcd Display Monitor /w HDMI 1.3 Input New Product Flysight Black Pearl RC801 LiteUS$ 140 - 185MOQ: 10 Sets -
G2716 2015 New Product Flysight Black Pearl RC801 Lite 1280*800 7 Inch HD Lcd Display Monitor Support HDMI 1.3 inUS$ 140 - 185MOQ: 10 Sets
-
G2715 New Arrival Flysight Black Pearl RC801 Lite 1280*800 7 Inch HD Lcd Display Monitor /w HDMI 1.3 Input AV InputUS$ 140 - 185MOQ: 10 Sets
-
G2714 Flysight Black Pearl RC801 Lite 1280*800 7 Inch HD Lcd Display MonitorUS$ 140 - 185MOQ: 10 Sets
-
G2713 Flysight Black Pearl RC801 Lite 1280*800 7 Inch Lcd Monitor With Hdmi Input NEW ARRIVALUS$ 140 - 185MOQ: 10 Sets
Product Description
1.Features
1. 7 inch 1280*800 display monitor
2. Support HDMI 1.3 in
3. Support image Zoom
4. Support image rotation 180 degree
5. Optional focus assist & false color
6. Detachable slim 3S battery
7. Support 2S-6S Lipo battery
8. Folded Sun shadow
9. Support standard bracket
10. battery volume intuitively showed way
2.Specifications
|
Display Screen |
Diagonal |
7 inch |
Resolution |
1280*800 |
|
Contrast |
800:1 |
|
Luminance |
400cd/m^2 |
|
|
AV Port |
AV OUT |
Video,Audio output |
AV IN |
Video,Audio input |
|
HDMI IN (A Type) |
Support HDMI 1.3 Input, Support HDMI Audio in |
|
|
Power supply |
DC IN |
7~28V/2A |
Battery |
11.1V/1000mAh (3S Li-po battery) |
|
Consumption |
12V input: 7.2W |
|
|
Demensions |
Main Body |
170X129X19.5mm (not include sun shadow) |
Battery |
105X87.5X6.7mm (not include prominent part) |
|
|
weight |
Main Body |
460g (include sun shadow,no battery) |
battery |
90g |
|
Tripod Connector |
General 1/4 “thread |
|
Working Temperature |
-10℃~ + 65℃ |
|
3.Function Icon
4. Two versions
Low end version & High end Version
low end version
Display Ratio
In AV IN Mode, press <M> button to display menu,again press <M> button to find <Display ration>, then press <+>/<->button to switch among Full scree /4:3/16:9.
In HDMI IN Mode,press <M> button to display menu,again press <M> button to find <Display ration>, then press <+>/<->button to switch among Full scree/4:3/16:9.
Image Zoom
Press <M> button to display menu,again press <M> button to
find <Zoom>,then press <+>/<->button to switch among off /X2/X4/X6.
Display Flip
In the menu ,Flip Horizontal is for image mirror display,Flip Vertical is for imager upside down display.
press <M> button to display menu,again press <M> button to find <Flip Horizontal> or <Flip Vertical>,
then press <+>/<->button to switch between on/off.
High end Version
Except the above 3 functions in low end version of the RC801 Lite,
for this high end version, there are more Great function as below.
Ratio Mark
Press <M> button to function menu,again press <M> button to
find <Ratio Mark>, then press <+>button to find aspect ratio (OFF/4:31.66:12:12.2:12.35:116:916:101.85:1),
then press <∨> or <∧> to choose the aspect ratio, last press <M> to confirm; or use <∨> Ratio Mark shortcut key
to realize this function directly.
Central Mark
Press <M> button to function menu,again press <M> button to find <central mark>,
then press <+>/<->button to switch between on/off.
False Color
Press <M> button to function menu,again press <M> button to find <False Color>,
then press <+>/<->button to switch between on/off. or use <-> false color shortcut key to realize this function directly.
Assist Focus
Press <M> button to function menu,again press <M> button to find <Assist Focus>,
then press <+>/<->button to switch between on/off. or use <+> false color shortcut key to realize this function directly.
Product Image
Black Pearl RC801 Lite
Black pearl kits RC801 Lite including:
Packing Details
1*Main Body
1*Sun Shadow
2*AV Cable
1*DC Input Cable
1*Battery
1*Charger
