stainless steel 316 316L 304 304L 1/4 1/4" in inch female npt bspt 5 valve manifold
Product Description
1. Specs
Instrument manifold are manufactured in accordance with ANSI B31.1, B31.3 and MSS-SP-105.
2-valve manifold are used with pressure gauges or pressure transmitters.
3-valve and 5-valve manifold are used with differential pressure transmitters.
working pressures:
Stainless steel up to 6000 psig (414 bar)
Alloy C-276 up to 6000 psig (414 bar)
Alloy 400 up to 5000 psig (345 bar)
Working temperatures:
PTFE packing from -65 F to 450 F (-54 C to 232 C)
Graphite packing from -65 F to 1200 F (-54 C to 649 C)
Orifice: 0.157 in. (4.0 mm), CV: 0.35
Upper stem and lower stem design, Stem threads above packing protected from system media
Safety back seating seals in fully open position
Testing for every valve with nitrogen at the maximum working pressure
2. How to order
Packing &Shipping
1. Packing
2. Shipping
Our Service
1. CAD drawing
2. P&ID
3. Component selection
4. Bill of material
5. Professional services such as bending and welding
6. Testing to guarantee the system
7. Professional packaging and delivery
Comapny Information
- Passed ISO9001-2000 & 2008
- Supply OEM/ODM Manufacturing.
- Designed and manufactured to intermix and interchange Swagelok ® and major global brands.
Hike Fluid Equipment Co., Ltd. now has more than 100 staff members, 20% of them are professionals who have rich experience in this field. The rich experience in product development we accumulated ensures us to customize products for the practical application needs of customers. We have more than 50 sets of precision CNC lathes, machining centers, slitting machines, cape cars, millings, sawing machines, washing, drying and testing equipment. Inspection center is equipped with a large number of test equipment and calibration standard parts, such as spectrometer, metallurgical microscope, quadratic element, projector, sclerometer, etc. We set up inspection test equipment calibration system and the maintenance management system.
The main products of Hike Fluid Equipment Co., Ltd. include needle valves, ball valves, instrument manifolds, bellows valves, check valves, twin ferrules series tube fittings, instrument pipe fittings, weld fittings and other kinds of instrumentation valves and fittings. We can provide stainless steel, alloy steel, brass, special alloy and carbon steel. The product executive standard of the company is ANSI, ASME, ASTM, API, MSS, ISO, EN, GB, JB, HG, etc.
FAQ
1. What is the acceptable MOQ?
For this 5 valve manifold , our acceptable MOQ is 1pc. Any trial order in small quantity is welcome.
2. What is the Delivery time?
For samples,we usually have them in stock, so the delivery time will be quite short .
For normal order, the delivery time should be in 2 weeks.
3.What is the acceptable payment term?
T/T, Paypal ,Western Union, MoneyGram, L/C, D/A, D/P
stainless steel 316 316L 304 304L 1/4 1/4" in inch female npt bspt 5 valve manifold
