high resolution 1280*800 tft lcd 10.1 touch screen with I2C interface
- 2500 Piece / Pieces per Month
- Shanghai/Ningbo China
- Credit Card
- negative segment character running machine lcd display,practical STN,blue backlight, fitness equipment
- digital fire alarm installation module display, HTN segment display with blue led lcd panel
- negative autoreclose circuit-breaker lcd display, segment module with blue led
- charger negative character lcd display,white led ,battery segment small flexible display
- character small charger lcd display ,custom battery display ,white led
- segment positive temperature time clock lcd display,blue TN white backlight
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | FANNAL | Model Number: | FN101AM08-V1.0 |
Type: | TFT |
Product Description
high resolution 1280*800 tft lcd 10.1 touch screen with I2C interface
Product Specification
Basic Information | Item | Specification |
Type | LCD with Capacitive Touch Panel | |
Model Number | FN043AM03-V1.0 | |
Size | 4.3 inch | |
Resolution | 480x800 | |
TFT Active Area | 93.60*56.16 mm | |
TFT Outline Dimension(W*H*T) | 105.55*62.50*2.15mm | |
TFT | Brightness | 350cd/m2 |
Panel Type | IPS | |
TFT Interface | TTL/8bit | |
CTP | Touch Points | 5 Touch |
Structure | G+G | |
CTP IC | CYTMA568-56 | |
Surface Hardness | 6H | |
Transmittance | > 87% |
Fannal's latest standard lcd touch module:
Basic information | TFT | CTP | ||||||||
Panel size | Resolution | P/N | LCD AA (mm) | Outline (mm) | Th(mm) | Brightness | Panel Type | Interface | Number of Touch | CTP IC |
4.3" | 480x800 | FN043AM03-V1.0 | 93.60*56.16 | 105.55*62.50 | 2.15 | 350 | IPS | TTL/8bit | 5 | CYTMA568-56 |
4.3" | 480*272 | FN043AM05-V1.0 | 95.04*53.86 | 105.50*67.02 | 2.95 | 300 | TN | TTL/8bit | 5 | CYTMA568-56 |
5" | 800*480 | FN050AM02-V2.0 | 64.80*108.00 | 76.30*120.70 | 2.95 | 450 | TN | TTL/8bit | 5 | CYTM568-58 |
7" | 800*480 | FN070AM13-V1.0 | 154.80*85.92 | 164.90*100.00 | 5.5 | 550 | TN | TTL/8bit | 5 | CYTMA568-56 |
8" | 1024*768 | FN080AM10-V1.0 | 162.00*121.50 | 183.00*141.00 | 3.5 | 250 | IPS | LVDS/8bit | 5 | CYTMA568-56 |
10.1" | 1280*800 | FN101AM08-V1.0 | 216.96*135.6 | 229.46*149.10 | 4.8 | 500 | TN | LVDS | 5 | CYTMA568-70 |
10.4" | 1024*768 | FN104AM01-V3.0 | 210.43*157.82 | 225.50*176.30 | 8.5 | 500 | IPS | LVDS/8bit | 3 | EETI |
12.1" | 1024*768 | FN121AM02 | 246.00*184.50 | 260.50*204.00 | 8.4 | 600 | IPS | LVDS/8bit | 3 | EETI |
Brief Introduction of Fannal's Capability and Service in LCD Display/Touch screen Area:
| small and medium size | Focaltech, Mstar, Goodix, Elan, Solomen, Synaptics , Cypress, Atmel |
medium and big size | EETI, SIS | |
CTP interface | USB,IIC,RS232,SPI | |
| Cover glass | AG/AF/AR, silk print,anti-vandal,logo printing |
Function | touch with water, oil,water-oil mixture,salt water touch with passive stylus | |
Sunlight Readablility Solution | High brightness TFT 500nit~1600nit Optical bonding AG/AR/AF coating
| |
Bongding size | CTP with tft: MAX 18 inch, CTP: MAX 27 inch | |
Quality certifications | SGS, UKAS Environmental Management Standard, IECQ,ISO9001,ISO14001 |
We have more than 10 years experience on industrial touch panel field.
We are ISO:9001, ISO:14001 Certified with Class 1,000 clean rooms.
We provide standard capacitive touch panel (1.28 ~42 inch)&LCD modules and custom touch solutions with sunlight readability,optical bonding,AR/AG/AF treatment on cover glass etc.
Our advanced equipment,quality raw material, precise process management methods and professional technical team generate our high quality products,and ensure long term supply.
We offer the best debugging and after sales services worldwide.
Our factory
All our products lcd touch screen are standard packed, for detailed information you can contact our customer service representatives.
Our company will deliver the order to you within one to eight weeks according to the details of the order.
Trade terms | FOB CIF EXW CPT |
Payment terms | T/T |
MOQ | Normally 1k, but depends on different products |
Lead time | 4~8 weeks |
1. Have you ever exported to foreign countries?
We have exported to Italy, UK, Poland, USA, Russia, Spain, Turkey, Ukraine, French, Colombia, Austria, Australia, Canada, Brazil, India and many other countries.
2. What is the lead time of the products?
Samples in stock will be delivered within a week after payment.
Mass production typically needs four to six weeks for delivery.
Tailor-made design drawings will begin after payment. The initial samples will be finished within 3 weeks after the drawing is approved.
3. What certifications do you have?
ROHS, ISO9001, ISO14001, TS16949, QC080000 and OHSAS18001
4. What is the MOQ?
It depends on different products. Please keep in touch with sales to confirm the MOQ.
5. How long is the warranty period?
Generally the warranty period is one year. It depends on different products.
