Help CenterProgrammable Thermostats
Related Products
Feature
1) Heating control
2) Programmable function of 24-hour per day and 7-day per week
3) 2 sets of permanent programs
4) Large LCD display
5) The Switching Difference is adjustable
6) Adjustable selection of comfort temperature, economic temperature, and antifreeze temperature;
7) Display adjustable between °C and F.
8)Three transmission modes for selection, i.e. wired, wireless or multi-channel transmission.
9)Fast and Simple installation.
Specifications:
Power supply: Two LR6 1.5v alkaline batteries, service life more than one year.
Range of temperature adjustment: 5÷35°C/39÷95°F
Range of temperature display: 0÷40 0C/32÷104°F
Temperature test frequency: Every minute
Display accuracy: 0.1°C/1°F
Probe sensor: NTC(100K) 1%
Protection level: IP20
Output: Switch relay
Contact capacity: 8A/250V (WW)
Insulating condition: Normal environment
Working environment temperature: -18÷50°C/0÷122°F
Running program: Set per 1 week as a cycle
Software level: A
Minimum allowable time for increase / decrease in program setting: 1 hour
Dimension (mm): 77H*121W*21D
Installation: Wall Mounted or with Battery Seat
Scope of Control Application
Control of wall-mounted boiler
Control of Thermal Actuator or electromagnetic valve
Control of water pump;
