Heating Thermostat

Feature

1) Heating control

2) Programmable function of 24-hour per day and 7-day per week

3) 2 sets of permanent programs

4) Large LCD display

5) The Switching Difference is adjustable

6) Adjustable selection of comfort temperature, economic temperature, and antifreeze temperature;

7) Display adjustable between ℃ and F.

8)Fast and Simple installation.

Specifications:

Power supply: Two LR6 1.5v alkaline batteries, service life more than one year.

Range of temperature adjustment: 5÷35℃/39÷95℉

Range of temperature display: 0÷40 ⁰C/32÷104℉

Temperature test frequency: Every minute

Display accuracy: 0.1℃/1℉

Probe sensor: NTC(100K) 1%

Protection level: IP20

Output: Switch relay

Contact capacity: 8A/250V (WW)

Insulating condition: Normal environment

Running program: Set per 1 week as a cycle

Software level: A

Minimum allowable time for increase / decrease in program setting: 1 hour

Dimension (mm): 77H*121W*21D

Installation: Wall Mounted or with Battery Seat

Scope of Control Applications:

1. Control of wall-mounted boiler
2. Control of Thermal Actuator or Electromagnetic Valve
3. Control of water pump;
4. Ventilation control.
