Specifications
24 Port Network Switch8324/IC + 1725 Chipset
24 10/100Mbps Auto RJ45 Ports
Size 440*206*44mm
Meet FCC, CE
Model: TH-1024S
24 port Network Switch / 24Port 10/100Mbps Ethernet Network Switch
Description:
What This Product Does
The 24-Port Fast Ethernet Switch TH-1024S is designed to meet the needs of the most demanding workgroup and departmental connectivity requirements. A reliable, easy-to-use switch without the complexity of management, the TH-1024S provides 24 10/100Mbps ports. The TH-1024s combines ease of use with unsurpassed performance resulting in an exceptional value for any cost-conscious network administrator who wants the best possible solution at the best possible price.
Ease of Use
The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDI-X crossover on all ports eliminate the need for crossover cables or uplink ports. Auto-negotiation on each port senses the link speed of a network device (either 10, 100) and intelligently adjusts for compatibility and optimal performance. Compact size make it ideal for desktops with limited space while it is also convenient and safe. Dynamic LED lights provide real-time work status display and basic fault diagnosis
Superior Performance
The rack-mount size metal case design combined with a safety certified internal power supply make the Switch the most robust product which is very cost-effective for a less than 48 user environment. Featuring non-blocking switching architecture,TH-1024sforwards and filters packets at full wire-speed for maximum throughput. With 10K Jumbo frame,the performance of large files transfers is improved significantly. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TH-1024s work reliably.
Photos:
Features:
l 100% Data filtering rate eliminates all error packets
l Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
l Non-blocking switching architecture forwards and filters packets at full wire-speed for maximum throughput
l 4.8Gbps Switching Capacity
l Auto-MDI/MDIX eliminates the need for crossover cables
l Supports MAC address auto-learning and auto-aging
l Support the port N-Way Auto-Negotiation, Store and Forward
l Compact size design for desktops
l Plug and Play design simplifies installation
Specification:
Hardware Features | |
Interface |
24 10/100Mbps RJ45 Ports |
AUTO Negotiation/AUTO MDI/MDIX | |
Chipset |
Realtek 8324/IC+1725 |
Mac Address Table |
8K |
External Power Supplier |
100~240VAC, 50/60Hz |
Dimentions(W×D×H) |
17.3*7.2*1.7 in. (440*360*44 mm) |
Software Features | |
Transfer Method |
Store and Forward |
Aavance Functions |
802.3X Flow Control, Back Pressure |
Auto-Uplink Every Port | |
Others | |
Package Contents |
TH-1024R |
Power Adapter | |
User Guide | |
Enviroment |
Operating Temperature: 0°C~40C ; |
Storage Temperature: -40°C~70C ; | |
Operating Humidity: 10%~90% non-condensing; | |
Storage Humidity: 5%~90% non-condensing | |
