Top Quality Cookware Pot Resistance Seam Welding Machine price
1. Description:
FZN100 is an automatic longitudinal welding machine, which may be used to weld material of carbon steel, low alloy steel, stainless steel, aluminum and alloys. The machine can use argon arc welding, gas protect welding, plasma weld and submerged arc welding system. It is very good to used in welding of pressure vessel, automobile accessory, electric home appliances and food machinery etc.
2. Feature:
The welding gun moves smoothly driven on a linear guideway
Speed of welding heed is adjustable based on material and thickness to weld.
Keyboard-type press plate with high-strength airbag, which will provide equalizing pressure on the working piece and keep it stable during welding.
Pneumatic align unit for welding edge aligning
Special design on press plate and spindle for heat dissipation
3. Specifications
Welding Capacity
Thickness scope 0.5-6 mm
Effective length 80-1000 mm
Diameter (mm) 60-860 mm
Welding Speed: 1002000 mm/min
Power: 800 W
Recommended welding power source: IGBT inverter MIG welder, 350 /400/500Amp
TIG welder 315
Top Quality Cookware Pot Resistance Seam Welding Machine price
A.Warranty : one year
B.Engineers available to serve machine overseas
C.Strict factory inspection
D.Complete equipment manual
E.Online instruction
F.Provide all components, spare parts and consumptive material
Metform seam-welding machine adopts three-phase inverter driving, welding speed is uniform, convenient adjustment, stable.Longitudinal sewing machine have painted the welding and welding two forms Metform seam-welding machine is widely applied in hardware, electrical appliances, automobiles, tank and other manufacturing industries, the most suitable for welding low carbon steel, stainless steel bowl, barrel, and sealed containers of thin-walled box.
To cater to the demands of transmission industries, Metform Machinery offer a complete range of hydraulic presses such as notching machines,iron workers,hydraulic press brake and shears punching machines, roll bending machine and many more. Sturdily constructed to perfection, our hydraulic presses can be operated easily and used for a long time. These premium quality hydraulic presses are known in international markets for excellent functioning, time saving and cost efficiency. They are offered by us at industry leading prices.
Top Quality Cookware Pot Resistance Seam Welding Machine price
