Help CenterIR Portable Whiteboard for Projector Use Infrared Interactive Whiteboard
Related Products
Specifications
IR Infrared interactive whiteboardActive area:150inch
Multi touch on teach software
English/Spanish/Korean/Italian
IR portable whiteboard for projector use infrared interactive whiteboard
|
Signal Receiver | |
|
Movement Detection Technology |
Infrared |
|
Active Area (max projection size) |
150 inch diagonal |
|
Active Area (horizontal angle) |
33 +/- 2 degrees |
|
Active Area (vertical angle) |
0-30 degrees |
|
Calibration Technology |
Infrared Positioning |
|
Active Distance (from projection screen) |
1.5 - 5 m |
|
Connectivity Interface |
1 x USB Cable (connection distance up to 40 m) |
|
USB Cable Standard Length |
6m |
|
Power Requirement |
DC 5V (from USB port) |
|
Power Consumption |
< 1.5 W |
|
Net Weight |
180 g |
|
Product Size |
84 x 66 x 39 (mm) |
|
Extendable Pointer |
E-Pen (Electronic pen) |
|
Movement Detection Technology |
LED Light |
|
Control Buttons |
2 buttons ( left and right click of a mouse) |
|
Power Requirement |
3 V CR123A x 1 |
|
Pen Body Dimension |
135mm (length); 10-20mm (diameter) |
|
Pen Body Weight |
85g (with battery) |
|
Pointer Extendable Length |
345 mm up to 676 mm (diameter: 10-13mm) |
|
Pointer Weight |
61g |
|
Stylus E-Pen | |
|
Movement Detection Technology |
LED Light |
|
Control Buttons |
2 buttons ( left and right click of a mouse) |
|
Power Requirement |
3 V CR123A x 1 |
|
Pen Body Dimension |
15cm (length); 18.5cm (diameter) |
|
Weight |
66g (with battery) |
|
System Requirements | |
|
OS Required |
Microsoft Windows 98/2000/xp/Vista/7 |
|
Processor Type |
Intel Pentium or above |
|
RAM Size |
128 MB |
|
Min Hard Drive Space |
30 MB |
|
Recommended Signal Receiving Distance | |
|
Projection Size |
Distance between Receiver and Projection Surface |
|
56 inch |
1.6 m |
|
68 inch |
2.1 m |
|
70 inch |
2.3 m |
|
75 inch |
2.5 m |
|
85 inch |
2.8 m |
|
92 inch |
3.2 m |
Our products cover the following categories:
* Interactive teaching products including portable interactive whiteboards, interactive projectors & matching products
* Large Size Multi-touch Solutions including Optical Imaging Touch Screens, IR touch screens, Touch AIO (All-in-One), Touch Tables
We share profit with you, join in to be a partner with us, be successful with our Interactive Multi-touch solutions.If any project we can help, pls email to sales1 at
