Sinotruk Homan 6x2 VAN TRUCK Cargo Truck
6x2 VAN TRUCK Cargo Truck Spec.
| Engine | Diesel:4-stroke direct injection diesel engine |
| Engine model: YN4102QBZL,EuroⅡemission standard | |
| 4-cylinder in-line with water cooling, turbo-charging and intercooling | |
| Maximum output: 116HP(85Kw)at 3000 rpm according to DIN | |
| Maximum torque:330 Nm at 1600~2000 rpm | |
| Number of cylinder:4 | |
| Displacement:3.76 L | |
| Bore:102mm | |
| Stroke:115 mm | |
| Compression ratio:17.5HP/L | |
| Specific fuel consumption: 205g/Kwh | |
| Thermostat with 71°C temperature saver | |
| Rigid fan | |
| Clutch | Single-plate diaphragm spring clutch, diameter 300 mm, hydraulically operating |
| Transmission | WLY transmission, model WLY646,synchromesh,6 forward & 1 reverse |
| Ratio:6.314 3.913 2.262 1.393 1 0.788 5.874 (R) | |
| Front Axle | 3.2t, forging forming of front axle I-beam, to guarantee the stiffness and high strength. |
| Rear Axle | 8.2t,mature punching welding axle and pressed axle housing |
| Ratio:6.33 | |
| Chassis | |
| Frame :ladder frame with section of 232×70×7 mm, all cold riveted cross members | |
| Front suspension: 9 leaf springs ,shock absorbers and stabilizer | |
| Rear suspention:12 main leaf springs+9 vice leaf springs, | |
| Spare wheel carrier: with one spare wheel | |
| Fuel tank: 160 L capacity | |
| Steering | LG9722470090,hydraulic steering with power assistance |
| Ratio: 19.12:1 | |
| Brakes | |
| Service brake: dual circuit compressed air brake | |
|
Parking brake (emergency brake):spring energy, compressed air operating on rear wheels | |
| Auxiliary brake: engine exhaust brake | |
| Wheels & Tyres | |
| Rims: 6.50-20(7.00T-20),6 hole-steel | |
| Tyres:8.25-20 tube | |
| Option:9.00-20 tube, 8.25R20tube 9.00R20tube | |
| Driver’s Cab |
Single cab with a sleeper, 45° hydraulically tiltable to the front, 2-arm windscreen wiper system with three speeds, adjustable driver’s seat, with heating and ventilating system, interior double sun visor, sunroof, radio and USB interface, safety belts,adjustable steering wheel, horn. |
| Electrics | |
| Operating voltage:24 V, negative grounded | |
| Starter:24 V,6 Kw | |
| Batteries:24 V,90 Ah | |
| Cigar-lighter, horn, headlamps, fog lights, indicators and reverse light | |
| Instrument Panel | |
|
Active check central controller with indicators, with this integral instrument the daily manual checks on the vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil pressure. | |
| Dimensions in mm | |
| Wheel base 4200 | |
| Front wheel track 1798 | |
| Rear wheel track 1764 | |
| Front overhang 1240 | |
| Rear overhang 2005 | |
| Approach angle(°) 27 | |
| Departure angle(°) 21 | |
| Overall dimension(L x W x H mm) 7445×2330×3400 | |
| Body size 5200×2150×2150 | |
| Weight in kg | |
| Dead weight(kg) 3750 | |
| Load weight(kg) 7000 | |
| Gross vehicle weight(kg) 10750 | |
| Performance | |
| Maximum driving speed(km/h) 95 | |
| Maximum grade ability(%) 30 | |
| Minimum ground clearance(mm) 238 | |
| Minimum turning circle(m) 16.8 | |
| Fuel consumption(1/100km) 20 |
Thank you for visiting XIAMEN LIANMEIDA TRADING CO., LTD.
We are the government company,also belong to Sinotruk Group.
We have rich experience dealing with all kinds of truck parts,
assembled truck and other special vehicles.
Our Key Advantages
1. Finished heavy truck sales including modification of tractor,
dump truck, tramcar, watering cart, cement tanker and other
special vehicles
2. Capable to customize different standards of emission and
configurations of trucks for different countries.
3.After- sales service and spare parts supply are able to solve
the pressing need of truck parts since we always keep large
inventory of spare parts such as cabin assembly, transmission
assembly, front, middle and rear axle assembly, chassis parts,
Euro II, Euro III, Euro V diesel engines and other different category
of truck parts.
4. Capable to supply you the best quality and the most competitive
price of heavy truck and spare parts to profit your business.
XIAMEN LIANMEIDA TRADING CO., LTD. is the best service platform
of heavy truck for you.
Q: I want to transport the truck by container, is it ok?
A: Yes, it is ok .But we need take apart the truck.You should reinstall in your country.
Q:How about your product quality?
A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Q:I want to be your agent in my country , is that ok?
A:It’s ok, If your quantity is big, we will consider. For the first time 50 units is ok.
Q:How about tyres ?
A: We can make the tyres as your requirement to suit your country's need.
New equipment inspection service: For Tractor, Dump Truck,
Cargo Truck, Tank Truck,Construction Equipment
- After-sales Service
- In-house training and Workshop
- Technical Support
- International Logistics Service
- Special Promotions
- Purchasing Solutions
- Maintenance Program
- Consultation Program
