CNC Turret Punch Press WKC3000-12/24 is fully automatic punching system, which consists of Turret Punching Machine, Feeding Table and CNC System.
- 1. Description and Features
Mechanical punching press, stable, reliable and easy for operation and maintenances
Independently developed CNC system, which will be upgraded periodically, and allow automatic conversion and punching from AutoCAD.
Automatic reposition function, better for large volume production.
Control unit: the industrial integration PC, shockproof, suitable for anti-jamming workstation work environments.
Inserted-sleeve Turret ensuing axiality of upper and down punching die as well as long usage life
Electric and Pneumatic are famous brand
linear guide way and precision ball screw.
Table surface with nylon brushes and balls
C type open press house, weld structure, stress relief annealed
Automatic protection for the Clamps.
Centralized lubricating system
Die station allocated as same as AMADA
Position |
Size(mm) |
WKC3000-24 |
WKC3000-12 |
A |
Dia. 3-12.7 |
12 |
4 |
B |
Dia. 12.7-31.75 |
8 |
4 |
C |
Dia. 31.75-50.8 |
2 |
4 |
D |
Dia. 50.8-88.9 |
2 |
---- |
Standard Accessories:
One sets of dies,
Sizing Block 6 pcs
Pedal switch 1 pcs
General tool 1 set
Spare Parts
Ball/brush for table surface, Seals, Friction Plate and Toothed Plate
- 2. Specification
WKC3000-24 WKC3000-12
Punching Capacity KN 250
Max. sheet size mm 1250×2500
Max. Sheet weight kg 120
Max. thickness mm 5
Hole Dia. With thickness mm Dia.50.8(δ≤2.9), Dia.31.75(δ≤4.5)
Max. punching Dia. In a hit mm Dia. 88.9 Dia.50.8
Die Station 24 12
Distance accuracy between holes ±0.1 mm(step pitch≤200)
Rate Hit rate HPM 140
Max. Feeding Speed m/min 32
Turret Rotation r/min 30
C type press body , weld steel structure annealed
3-Axis Controlled X-Axis, Y-Axis and T
Lubrication Automatic
Pneumatic Clamps 2
Standard punching dies, the same AMADA
Power Supply W 7200
Pneumatic presure MPa 0.55
Overall Size mm 4900×3200×2200
Net weight kg 9700 9200
