Specifications
Portable Hydraulic Shearing Machine FM-Q1101.High Speed Operation
2.Robust Compact Design
3.Easy In Operation
Portable Hydraulic Shearing Machine FM-Q110
The machine is integrated,compact and portable.
Main Technical data
Nominal Force 80T
Stroke Time ≤5S
Cutting Capacity (for mild steel tensile strength 450MPa)
Angle Steel at 90°110×110×10
at 45°80×80 mm
Channel 100×48×5.3 mm
Plate 150×10 mm
Rod 40 mm
Hydraulic working presure 25MPa
Hydraulic Oil H46
Motor 4.0 KW
Power 380 V 50Hz
Overall Size 400×400×1000 mm
Net Weight 186 Kg
Company Introduction
Metform ( Shanghai) machinery Co., Ltd., located in Songjiang Shanghai, was established in 2004. Metform specializes in design and manufacture of special machine for metal strip manufacture and forming. We are designers and builders of high quality metal coil processing line. We supply machines with latest available technology, design and innovation in machinery engineering. The main product are spiral tube forming machine, folding machine, Lock forming machine and bending machine etc for air duct, as well as various specification of small 2 high/ 4 high mill, slitting and cut-to-length line. Metform deals and exports a wide variety of machines for metal sheet processing and used Construction equipment too. The promise of Metform is to produce machine with excellent quality, diligently satisfy the customer's need and create value for you by means of our products and service.
Main Products
machinery equiment- seam welding machines, spiral tube forming machines, elbow making machines, roll bending machines, angle steel flat steel volume circle machines, lock formers, hydraulic notching machines, hydraulic combined punching and shearing machine, CNC plasma/ laser cutting machine, punch presses, metalworking machines, coil processing machinery, leveling machine, slitting line, cut-to-length lines, rolling mills.
