MFJ280 Rubber Grinder is a device that granulates the 5-20 mesh pure rubber grains into 40-120 mesh powder at normal temperature.
It mainly insists of: main motor, servomotor, VF motor, V belt wheel, fixed millstone, movable millstone, main shaft, body and cooling water circulation system, Circulating cooling water systems and other components
1.Horizontal structure guarantees the installation accuracy of millstones and easy operation.
2.Compact structure, low power consuming, high output, lownoise and easy installation.
3.Tungsten carbide millstones can stand strike, wearesistant and are flexible. Easy maintenance and long service life.
4.Built-in cycling cooling water system prevents the high temperature and avoids rubber charring when mil
lstones working, and improves the efficiency and lengthens cutter life.
5.VF motor with stepless adjustment features.The grinder clearance is fixed, adjustment is not needed
Motor Power |
30 |
KW |
Main shaft speed |
750 |
r/min |
In feed size |
<5 |
mm |
Output size |
40-120 |
um |
Capacity |
80-180 |
Kg/h |
Way of working |
Cyclic shear |
|
Noise |
<50 |
db |
Weight |
1000 |
Kg |
1. The machine is used for mixing the natural rubber, used to make good quality of reclaimed rubber from used tire and mixing after desulfurization.
2. This machine is suitable for reclaimed rubber plant,conveyor factory,rubber products fatory,shoe factory,cable plant,seals and other related industries.
3.The complete equipment is at room temperature without any pollution, is using physical methods to break down waste tires into steel wire and rubber particles or powder, it can re-use of waste tires into renewable resources, “black gold”.
1 one year warranty and life-long technique supporting.
2. Engineers are available to help install and debug
3. Our company can provide the safe operation training, the maintain and repairing of
equipment training freely.
4. For the damage caused by the user, our factory provides the parts and repairing with best price.
Packing details: A layer of plastic wraps to protect machine, wooden case as the outside package, or as your requirements.
Shipping details: 40- 90 days
