Duct Manufacture Auto Line 5/Square Duct Auto Machines/Air Duct Line
- 1. Description and Feature
Metform’s Duct line features with highly efficiency and automatic and also saves material. It is very suitable for mass production of square duct manufacture.
Auto-line V is consists of feeding frame, leveling, grooving roller machine, hydraulic punching and square notch equipment, mechanical hand fixed position feeding frame plat, double drive TDF flange former and double drive singe hem former, servo feeding plat and TDF hydraulic folder.
All systems is controlled by a computer. The feeding is by servo with precise location. When producing “Square”shape duct, the folding is with high precision. The maximum work speed is 16m/min. The diagonal line tolerance is ±0.5mm.HCH-V can produce 2 kinds of ducts: TDF flange and angle iron flange.
It saves work space, with linear type structure,
high efficiency. It can produce“square”shape duct with small section, the minimum section area of TDF duct is 200×200mm.
2. The Line Process Schematic Diagram
- 3. Specification
minimum section area of TDF duct is 200×200mm
Thickness: 0.6-1.5,
Width: 1300 mm
Working speed: max. 10 m/min
Coil weight: 6500 kg
Main unit sizes: 29500×5400×1500 mm
Weight: 20000 kg
- 4. Supply Scope:
- a. 2 sets of power feeding frames(3000x1900x950mmx2)
- b. Leveler,grooving roller machine,nothing die,shearer
- c. Movable pittsburgh lock forming machine
- d. Power feeding frame
- e. Double drive TDF flange former
- f. Doulble drive singe hem(angle iron) Flange former
Metform ( Shanghai) machinery Co., Ltd., located in Songjiang Shanghai, was established in 2004. Metform specializes in design and manufacture of special machine for metal sheet/strip manufacture and forming. We are designers and builders of high quality metal coil processing line. We supply machines with latest available technology, design and innovation in machinery engineering. The main product are spiral tube forming machine, folding machine, Lock forming machine and bending machine etc for air duct, as well as various specification of small 2 high/ 4 high mill, slitting and cut-to-length line. Metform deals and exports a wide variety of machines for metal sheet processing and used Construction equipment too. The promise of Metform is to produce machine with excellent quality, diligently satisfy the customer's need and create value for you by means of our products and service.
Main Products
machinery equipment- seam welding machines, spiral tube forming machines, elbow making machines, roll bending machines, angle steel flat steel volume circle machines, lock formers, hydraulic notching machines, hydraulic combined punching and shearing machine,CNC plasma/laser cutting machine,punch presses, metalworking machines,coil processing machinery, leveling machine,slitting line, cut-to-length lines, rolling mills.
Spiral corrugated steel culvert tube forming machine with high quality
A.Warranty : one year
B.Engineers available to serve machine overseas
C.Strict factory inspection
D.Complete equipment manual
E.Online instruction
F.Provide all components, spare parts and consumptive material
cost effective Spiral corrugated galvanized pipe forming machine with top quality
high strength spiral steel pipe making machinery from factory
High quality Spiral Tube Roll Forming Machine metal sheet 0.4-1.2mm for sale
Q:How to get a accurate quotation from us?
A:provide us the detail of the material such as metal thickness and width
Q: You are Manufacturer or trading company?
A: We are 100% manufacturer with 17 year's manufacturing experience
Q: Can you do OEM service?
A: Yes, we can. Your design is accepted. Your own logo can be used on the machine.
Q:what’s the shipping cost from China to your country?
A:We can send machine to your port or door address by sea or airplane. Please kindly tell us your nearest port or address with postcode.We have reliable shipping agent to insure the safe,convenient and timely delivery.
Q: How to check imported charges or tax ?
A:Call your l them machine HS code.
Spiral duct forming machine is 8455229090
Press brake and rolling machines are 84622990. shearing machine is 84623990.rolling machine is 8455229090,seam welding machine is 85152900
Q: Do you accept LC payment?
A: Yes. Normally, our payment is 30% +70% TT. LC payment is also acceptable.
Q: what’s the package?
A:fumigation-free plywood case or without package
Q:How to operate this machine ?
A:video link of our factory .......or we send you the movie directly
Q:what about commissioning service ?
A:we can offer commissioning service,the buyer need to afford plane tickets
Q:Do you offer teaching&training ?
A:Training at supplier’s plant
Q: what’s policy for guarantee and broken parts?
A:Warranty period of equipment lasts a year, during which the broken parts
