Heat Pipe Heat Exchanger
Heat Pipe is constructed of a sealed metal tube with a certain amount of fluid in a partial vacuum. Heat is absorbed at one end by vaporization of the fluid and is released at the other hand of condensation of vapor.
Pipe
Pipe Material:Carbon Steel (AL fin,CS fin), Stainless Steel (SS fin)
Type: Round
Diameter: Φ16 mm
Length(mm): 500/800/1000/1200/1500/1800/2000
Single Pipe Heat Load(W):40/101/150/221/310/446/558
Fin
Material: Aluminum, Carbon Steel and Stainless Steel
Structure: Aluminum Rolled, High Frequency Welded
Key Benefits:
* Increase heating efficiency by 3-12%
* Reduce 3-8% fuel consumption with the same value of produced power
* Reduce carbon dioxide emissions
* Recycle waste energy
* Cost saving and environment protection
Key Characters:
* High heat transfer coefficient and high heat transfer temperature difference
* Perfect tightness guaranteed by special sealing process
* Long service life with high level security
* No moving parts or additional power consumption
* easy to clean
Packaging according to custmer's requirement
Shipping Port: Shanghai
Applied in Cereal & Oil Industry, Paper Coating Industry, Chemical Industry, Food and Beverage Industry, Feed-processing Industry etc.
