Specifications
Golden Brush Finishing Aluminium Composite Panel1. Panel thickness 2-6mm
2. Alu thickness 0.06-0.5mm
3. PE and PVDF Coated
Product name: Golden Brush Finishing Aluminium Composite Panel(ACP)
Aluminium Composite Panel Place of origin: China
Golden Brush Aluminium Composite Panel(ACP)
1.Coating: PVDF/PE
2.Core: unbreakable/ breakable LDPE core
3.ISO9001:2000 and SGS certificate
Golden Brush Aluminum Composite panel(ACP)
1. Standard:
according to GB/T 17748-1999 standard
2. Material:
a) Front: aluminum alloy sheet coated with fluoro-carbon resin
(PVDF) and polyester resin (PE) roasting painting
b) Core: nontoxic polyethylene.
c) Back: aluminum alloy sheet coated with polyester resin painting
d) Surface finish: treated with PVDF and PE resin rolling roasting .
coating
e) Surface coating thickness: 30um
f ) Aluminum alloy sheet thickness: 0.1mm, 0.12mm, 0.15mm, 0.2mm,
0.3mm, 0.4mm, 0.45mm, 0.5mm
3. Dimensions:
a) Thickness: 3mm, 4mm
b) Width: 1220mm 1500mm..
c) Length: 2440mm, 3200mm, 4000mm,5000mm (max: 6 meter)
d) Weight: 5.5kg/sqm based on 4mm thickness.
e) Standard size: 1220 x 2440mm
f) Nonstandard sizes are available according to requirement of customers
Description:
Fire-Resistant Aluminum Composite Panel is a composite material made of aluminum and non-combustible mineral filled core. Though the core material does contain a small amount of combustible polyethylene, the main ingredient of the non-combustible mineral filled core does not permit the proliferation of flame and restricts smoke. It is a fire-safe material that passes mandatory requirements for exterior and interior application.It is an ideal material for external claddings, roof of pedestrian passage and other architectural applications.
Golden Brush Aluminum Composite Panel (ACP) or Aluminium Composite Material (ACM) is a widely-used term describing flat panels that consist of a non-aluminium core bonded between two aluminium sheets. Aluminium sheets can be coated with PVDF or Polyester paint. ACPs are frequently used for external cladding of buildings (building facades), for insulation and for signage.
Specifications:
1) Panel thickness: a) 4mm (standard) b) 5 - 6mm available upon requests
2) Aluminum skin thickness: a) 0.50 x 0.50mm b) 0.45 x 0.45mm c) 0.40 x 0.40mm d) 0.30 x 0.30mm e) 0.20 x 0.20mm
3) Width: a) 1,220mm (standard) b) Maximum width is 1,600mm c) Other widths available upon requests
4) Length: a) 2,440mm (standard) b) Up to 6,000mm (recommended)
Features:
1) Fireproof and water resistant, excellent heat and sound insulation
2) Excellent surface flatness and smoothness
3) Superior weather, corrosion and pollutant resistance
4) Even coating, various colors
5)Super peeling strength
6) Superior impact resistance
7) Lightweight and easy to process
8) Easy to maintain
Applications:
1) Building exterior curtain walls
2) Decoration and renovation additions for old buildings
3) Decoration of interior walls, ceilings, bathrooms, kitchens and balconies
4) Shop door decoration
5) Advertisement board display platforms and signboards
6) Wallboards and ceilings for tunnels
7) Industrial materials and materials for vehicles and boats
