Decoration wire for colthes and bags High Brightness Welted EL wire-grass green
- 20000 Meter / Meters per Month
- Shenzhen
- 6.56 foot (2 meter) White EL Wire set
- Multicolor Luminous EL Wire Roll
- 3.2mm High Brightness EL wire
- Diameter 2.3mm Blue High Brightness EL wire
- EL Wire Driver,2*1.5V(AAA) Sound control Battery driver,3VDC Sound control battery inverter
- 25ft EL Wire with 8*1.5V(AA) Battery driver EL wire Kits, Battery inverter
Product Details
Place of Origin: | Hubei, China | Brand Name: | EL | Model Number: | CK-ELW-2.3B-X |
Packaging Details
50m/box, 100m/box,200m/box,300m/box, 12 boxes/ carton
Product Description
1.Technical parameters of our High brightness EL wire:
(1) Working voltage:50-120V; Optimal operating voltage:110V.
(2) Working frequency: 800MHZ-1200HZ; Optimal frequency:1000Hz.
(3) Static capacitance: 6.5nf/m(20°C RH<80%).
(4) illumination intensity: 200cd/m2(110V 1000HZ).
(5) Power consumption: 43mW/M (110V 1000HZ).
(6) Lifetime: 6000-7000 hours(100V ,1KHz)
(7) Working temperature: -20°C~+70°C.
(8) Relative humidity: RH<90%.
(9) Storage temperature:-10°C~+40°C
(10) Storage relative humidity:RH<65%.
2.Basic specification of High Brightness EL wire with single welted.
(1)Basic diameter:2.3mm
(2)Mainly color: Red, Lemon, Aqua, Orange, Grass green, Blue, Purple, Pink, Gold Yellow , Fluorescent Red, White.
(3) Max Length: 100M/Roll
(4)Notice: I can make it according to the customer need Diameter and Size, But MOQ: 500M
3.Picture show:
4.Our advantages:
(1) Huangshi Changkai Electrical Co.,ltd has specialized in EL products above 10 years and has enjoyed a high reputation in the field.
(2) Our company produced EL wire have US Invention Patent and China Invention Patent.
US Invention Patent No.: US 6.960,725 B2
China Invention Patent No.: ZL 03 1 40836.2
(3) Diversified diameters and colors.
Basic diameter:2.3mm
Main colors:Red, Lemon, Aqua, Orange, Grass green, Blue, Purple, Pink, Gold Yellow , Fluorescent Red, White.
(4) Powerful production capacity:Our factory can manufacture 2000 meters EL wire of different colors everyday.
(5) Enthusiastic service.
Company Profile
Huangshi Changkai Electric Co.,Ltd was set up in 2002, is located at high-tech development zone of huangshi,hubei province.It is a professional el products manufacturer,which specializes in R&D,manufacturing and sales of all kinds of special el wire. We changkai owns advanced equipment and gathers a number of el products talents,which possess the rich experience of R&D and a strong capabilty of technology innovation which has developed el wire,el chasing wire and el visible flowing cable ,ect.we own the invention patent of the products in China,America and PCT.
Changkai colorful EL wire is a kind of environment-friendly and power-saving decorative products.it takes unique manufacturing process,which is mild in color,uniform glow,long service life,low power consumption, waterproof,anti-aging and flexible.they are widely applied into decoration,decorative lighting,gift, toy and advertising industry. our polychrome el wire series products is more than ten items,which includes single core wire,multicore wire,the integration of multicore wire and parallel core wire.we have more 12 colors for your reference, which includes white,red,pink,purple,blue,aqua,grassgreen,lemon,yellow,organge,transparent blue,fluorescent red,ect.
Changkai lead the market by the advanced technology and has exported our products to europe ,America and many other countries and regions . We are holding the principle of originality,innovation and creativity,insisting the management concept of making combination of tecnology and art,trying our best to develop as the world's biggest el wire manufacturer,to build we changkai as an authoritative brand in electrooptical technology industry.
