Specifications
6m 8m 10m 12m electric scissor lift 220v1. mobile driving and lifting system
2. lifting height 3m to 12m
3. manuf
6m 8m 10m 12m electric scissor lift 220v
Basic Information
| Factory | Ruyi Handling Machinery Factory |
| Factory Location | Taizhou |
| Product Name | 6m 8m 10m 12m electric scissor lift 220v |
| Model | RC-S |
| Lifting Height | 12M |
| Load Capacity | 1000KG |
| MOQ | 1 PCS |
| Warranty |
12 months (not include the easy-worn parts); Extended Warranty for optional |
| Battery |
Lead acid battery, can full charge-discharge 750 times; maintenance-free battery for optional |
| Payment | T/T,L/C,Western Union |
| Delivery Time | 7 workdays |
| What's Included | (1) Stacker (2) 12V/24V batteries (3) Battery charger |
Pictures
Technical Data
We accept any custom-made specification of high quality taizhou hydraulic scissor lift table
Hereinafter the parameters are only for reference.
| Model | Unit | MWP0.3-6 | MWP0.5-6 | MWP1-6 |
| Load capacity | kg | 300 | 500 | 1000 |
| Operational height | mm | 6000 | 6000 | 6000 |
| Table size (L×W) | mm | 2050×1050 | 2050×1150 | 2050×1250 |
| Minimum height | mm | 1950 | 2080 | 2200 |
| leg's length | mm | 1000 | 1050 | 1100 |
| Motor power | kw | 1.5 | 1.5 | 2.2 |
| Lifting speed | mm/s | 45 | 45 | 50 |
| Tubing-pressure | Mpa | 12 | 12 | 12 |
| Weight | kg | 600 | 650 | 720 |
| Model | Unit | MWP0.3-7 | MWP0.5-7 | MWP1-7 |
| Load capacity | kg | 300 | 500 | 1000 |
| Operational height | mm | 7000 | 7000 | 7000 |
| Table size (L×W) | mm | 2050×1050 | 2050×1200 | 2050×1300 |
| Minimum height | mm | 2080 | 2180 | 2480 |
| leg's length | mm | 1000 | 1100 | 1250 |
| Motor power | kw | 1.5 | 2.2 | 2.2 |
| Lifting speed | mm/s | 60 | 60 | 70 |
| Tubing-pressure | Mpa | 15 | 15 | 12 |
| Weight | kg | 680 | 750 | 820 |
| Model | Unit | MWP0.3-10 | MWP0.5-10 | MWP1-10 |
| Load capacity | kg | 300 | 500 | 1000 |
| Operational height | mm | 10000 | 10000 | 10000 |
| Table size (L×W) | mm | 2250×1250 | 2250×1300 | 2500×1450 |
| Minimum height | mm | 2350 | 2480 | 2720 |
| leg's length | mm | 1200 | 1250 | 1400 |
| Motor power | kw | 2.2 | 2.2 | 3 |
| Lifting speed | mm/s | 80 | 90 | 85 |
| Tubing-pressure | Mpa | 16 | 16 | 16 |
| Weight | kg | 1100 | 1250 | 1750 |
| Model | Unit | MWP0.3-12 | MWP0.5-12 | MWP1-11 |
| Load capacity | kg | 300 | 500 | 1000 |
| Operational height | mm | 12000 | 12000 | 12000 |
| Table size (L×W) | mm | 2600×1500 | 2600×1500 | 2600×1500 |
| Minimum height | mm | 2720 | 2720 | 2720 |
| leg's length | mm | 1450 | 1450 | 1450 |
| Motor power | kw | 2.2 | 3 | 3 |
| Lifting speed | mm/s | 100 | 100 | 100 |
| Tubing-pressure | Mpa | 16 | 16 | 16 |
| Weight | kg | 2200 | 2400 | 2600 |
Services
1. We supply spare parts free for one year, and supply the technical supporting all the time.
2. As a factory, we provide good after service,we can arrange spare parts in 24 hours.
3. All emails will be replied in 24 hours.
4. OEM service provide, print your own design and pattern on the product
5. Protection of your sales area, ideas of design and all your private information.
6: Price-lists are available,welcome to ask.
Packaging
1)Normal Packing.
Inner Pack: Bubble Film + PP Knitted Band
Outer Pack: Wrapping Film + Iron Pallet
2)Plywood case packing for optional
Shipping
The transportation depends on client's choice, usually by sea, by train ,by air etc.You also can choose other shipping method and inform us before shipment.
How to make an order
To get the Prompt & Accurate Quotation , please tell us:
Product Name?
Hand Type? Stational type or mobile type? Self-propelled?
Load Capacity?
Lifting height?
Local power? 220V? 380V?110V? etc.
Have other special demands?
Brief introduction
Ruyi Factory is professional in producing material handling machinery and material lifting machinery ,such as Electric Stacker, Electric Pallet Truck, Electric Order Picker, Hand Stacker, Hand Pallet Truck, Scissor Lift,Work Platform etc.
1.The lifting height of Electric Stacker is 1m ,1.6m, 2.5m,3m ,3.5m,4.5m,5m,5.5m and so on. Max lifting height can reach 5.8m.
2.The load capacity of Electric Stacker is 500kg,1000kg,1500kg,2000kg and so on. Max load capacity can reach 3000kg. Electric Pallet Truck max load capacity can reach 10000kg.
3.The Electric Stacker is easy to control. Even the an femal worker can drive it easily.
4.Power supply : 110v, 220V,240v, 400v etc. We will customize the charger to meet clients' local power.
