Home > Manufacturing & Processing Machinery > Textile Machinery & Parts > Nonwoven Machine > S/SS/SMS PP Spunbond Nonwoven Fabric Making Machine
S/SS/SMS PP Spunbond Nonwoven Fabric Making Machine
US$ 290,000 - 1,360,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Automatic Grade:
Automatic
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
S/SS/SMS PP Nonwoven Fabric Making Machine in ChinaUS$ 330,000 - 1,370,000MOQ: 1 Set -
Professional Design of pp Spunbond Non Woven MachineUS$ 300,000 - 1,370,000MOQ: 1 Set
-
1600-3200mm pp Spunbond Non Woven Textile MachineUS$ 300,000 - 1,310,000MOQ: 1 Set
-
Professional Design Spunbonded Non Woven Production LineUS$ 300,000 - 1,360,000MOQ: 1 Set
-
New Design Nonwoven Spunbond MachineUS$ 290,000 - 1,370,000MOQ: 1 Set
Condition
New
Automatic Grade
Automatic
Place of Origin
Jiangsu, China
Brand Name
Sanyang
Model Number
SY-1600,SY-2400,SY-3200
Voltage
380V
Power(W)
130-800kw
Dimension(L*W*H)
12m*17m*10.5m
Weight
60-190ton
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
-non woven fabric making machine-advanced technology, reasonable design
-1 year warranty
This production line is filament polypropylene fiber spun bounded non-woven fabric equipment. Its raw
material is polypropylene (PP), take the principle of spinning man-made fibers, during polymer filature,
continuous filament is extended into fiber net, which is finished by mechanical hot pressing. The machine
assembly we adopt is now advanced veneer integer slot air flow draw technology; the whole process from material feeding to cloth output is automatic control, short production flow, high working efficiency.
The non-woven fabric we produce has high strength, good softness, innocuity, bacterium – proof,
corrosion resistance, high – level draw strength & elongation rate. They are widely used for dress,
decoration materials, medical sanitation materials, daily life products & in the industrial, agricultural
fields. In addition, this production line can produce non-woven fabrics of different color, different grams,
and different lines according to users’ requirement.
material is polypropylene (PP), take the principle of spinning man-made fibers, during polymer filature,
continuous filament is extended into fiber net, which is finished by mechanical hot pressing. The machine
assembly we adopt is now advanced veneer integer slot air flow draw technology; the whole process from material feeding to cloth output is automatic control, short production flow, high working efficiency.
The non-woven fabric we produce has high strength, good softness, innocuity, bacterium – proof,
corrosion resistance, high – level draw strength & elongation rate. They are widely used for dress,
decoration materials, medical sanitation materials, daily life products & in the industrial, agricultural
fields. In addition, this production line can produce non-woven fabrics of different color, different grams,
and different lines according to users’ requirement.
Description of Spunbonded nonwoven plant
Items |
Specifications |
Effective breadth(mm) |
1600,2400,3200 |
Production capability(T/Y) |
1500,2200,3000 |
Weight range(g/m2) |
9-200 |
Installed capacity(kw) |
130,220,300 |
Filament denier |
≤2.5D |
Screw diameter(mm) |
130-170 |
Length-diameter ratio |
30:1 |
Parts of spunbonded nonwoven fabric production line:
Screw extruder --->Rim charge auxiliary screw and recycling device ---> Spinning beam --->Filter--->Metering pump--->Monomer suction device--->Quenching air chamber--->Stretching device--->Calender--->Tension device--->Winder and suction system.
Spunlaid process and technical flow chart:
Additive(recycling waste edge)---> Raw material -->Melting--> Filtering-->Measuring-->Spinning-->Cooling-->Stretching-->Web forming-->Calendering-->Rounding-->Final products
Output per year |
Total capacity |
operating power |
Power consumption |
Size |
|
1.6 meter single spinning beam machinery |
1500ton |
360kw |
130kw |
800kw*h/ton |
10*15*12.5m |
1.6 meter double spinning beam machinery |
3000ton |
720kw |
260kw |
800kw*h/ton |
10*25*12.5m |
2.4 meter single spinning beam machinery |
2200ton |
540 kw |
220kw |
800kw*h/ton |
14*20*12.5 m |
2.4 meter double spinning beam machinery |
4400ton |
1080kw |
440kw |
800kw*h/ton |
14*30*12.5m |
3.2 meter single spinning beam machinery |
3000ton |
720kw |
300kw |
800kw*h/ton |
17*20*12.5 m |
3.2 meter double spinning beam machinery |
6000ton |
1440kw |
600kw |
800kw*h/ton |
17*30*12.5m |
We can also change the effective fabric width to fit clients' special requests.
PP spunbonded nonwoven fabric production line:
Customer's finally market :
