Jacket 4-way melt valve.Control Valve
Operation: Manual, Electric
Inspection and Test: API STD 598
Design STD: ANSI B 16.34
Catheter Material: 304, 316
Core Material: 304, 316, 304L, 316L
Suitable Medium: HTM
Inside Tube Suitable Medium: Lipid, Polymer, Fusion
Suitable Design Temp.: ≤330
Core Design Temp.: ≤360
Valve Size: DN50~DN400 (1inch~16inch)
Jacket Class: 0.6~2.5 Mpa 150LB
Core Class: 0.6~42 Mpa 125LB~2500LB
No dead angle; Apply to the state of high-pressure and Vaccum; Actuating; Electric, Worm gear
Design of the Flow channel : straight line designs
Connection type of fuse pipe: Flange coupling/ Butt welding
Connection type of heat medium: Flanges/ Butt welding
Hard seal of valve stem : valve stem and valve body welded with carbide alloy to ensure the abrasion resistance of the sealed surface
