INVERTER DC TIG WELDING MACHINE

Specifications

largest of our general level TIG welding machine
adopt PWM inverter technology
high duty cycle and power efficiency

   TIG-300 Inverter DC TIG welding machine is the largest of our general level TIG welding machine.

   The thickness of welding plate should be 0.5-4.5mm. It is the same as TIG-250 that adopts PWM inverter technology. It has excellent arc performance with the success rate of 100%. It has high duty cycle and power efficiency.

    Besides, our product makes use of soft switching technology to improve its performance. It is particularly suitable for stainless steel decoration, kitchen equipment, stainless steel products and other industries.



Rated Input Voltage	three phase 380V±10%
No-load voltage	65V
Output current Range	10-300A
Post flow time	1-10S
Rated Input Power	8.25KVA
Rated Input Current	12.4A
Rated Output Current	300A
Rated Load Voltage	22V
Duty Cycle	60%
N.W.	15KG
Dimension(L×W×H)	550×270×400mm
