Hankison technologyPerfect refrigerated system
Energy Conservation
Condenser made from fin copper
ISO9001:2008 & CE
Compressed Air filter:
Product introduction:
Grades:totally 5 grades as HF9,HF7,HF5,HF3,HF1.
ing pressure :10kgf/cm²(10bars)
Max.temperature of element :66°C
New element is using superior duralumin,with the epoxy resin powder interior and exterior to improve the wear well and corrosion resistant,
New housing with compact design,it can be series-parallel connection in order to save spaces.
Optional parts:auto-drain,pressure indicator,differential pressure gauge,and liquid indicator.
A choice of five elements allows you to design a system that delivers the air quality you require.
Push-on type element:replacement easy
Piston type elements to housing seal:prevents unfiltered air through filter directly
Corrosion resistant cores:Stainless steel for added structural integrity
Low resistance to flow,Seam welded for extra strength
New “matrix blended fiber”media:Large,effective surface area_improves capture rate-ensures high efficiencies,Large open area minimizes pressure drop
Coated,closed cell form sleeve:Resists chemical attack from oils and acids;Ensures high efficiencies by preventing re-entrainment of coalesced liquids
Chemically resistant end caps bound to media with specially formulated adhesive silicone free
Withstands temperatures to 66°C
Five grade of precision for choosing:
1). Separator filter (HF9)
For bulk liquid removal plus a 3 micron coalescer (5ppm w/w maximum remaining oil content)
Two-stage filtration
* First stage: two stainless steel orifice tubes provide 10 micron mechanical separation
* Second stage: in-depth fiber media captures solid and liquid particles to 3 micron
2). Air line filter (HF7)
For removal of liquid water and oil; removes solid particles to 1 micron (1.0 ppm w/w maximum remaining oil content)
Corrosion resistant inner and outer cores
Two-stage filtration
* Firt stage: captures larger particles with alternate layers of fiber media and media screen
* Second stage: coalesces aerosols and captures solid particles with multiple layers of epoxy bonded, blended fiber media
3). High efficiency oil removal filter (HF5)
For coalescing fine water and oil aerosols; removes solid particles to 0.01 micron (0.01 ppm w/w maximum remaining oil content)
Corrosion resistant inner and outer cores
Two stage filtration
* First stage: multiple layers of fiber media and media screen remove larger particles pre-filtering the air for the second stage.
* Second stage: multiple layers of bonded, blended fiber media for fine coalescence
Outer coated, closed cell foam sleeve
4). Ultra high efficiency oil removal filter (HF3)
For coalescing ultra-fine oil aerosols; removes solid particles to 0.01 micron (0.001 ppm w/w maximum remaining oil content)
Corrosion resistant inner and outer cores
Two stage filtration
* First stage: coated, closed cell foam sleeve acts as pre-filter and flow disperser
* Second stage: multiple layers of matrix blended fiber media for ultra-fine coalescence
Outer coated, closed cell foam sleeve
5). Activated carbon air filter (HF1)
For removal of oil and hydrocarbon vapors normally absorbable by activated carbon; removes solid particles to 0.01 micron (0.003 ppm w/w maximum remaining oil content)
Corrosion resistant inner and outer cores
Two stage filtration
* first stage: stabilized bed of finely divided carbon particles removes the majority of the oil vapor
* Second stage: multiple layers of fiber media with bonded micro fine carbon particles remove the remaining oil vapor
Multiple layers of fine media prevent particle migration
Outer coated, closed cell foam sleeve prevents fiber migration
Designed life is 1000 hours under rated conditions.
Model,Size &Technical Data
