Specifications
The aluminum trailer/Aluminum tank truck
1.Aluminum trailer body lighter, stronger, under the condition of the limit load,can carry more goods.
2.Aluminum alloy fuel tanks, lighter weight, and oil not easy to react, environmental protection, safe and efficien.
We can design and manufacture crude oil tank semi trailer according to your exact requirements.
Delivery :
Delivery Detail :within 15 days after receive 30% contract value as deposit
Tank Body | |
Shape |
Cylindrical |
Dimension |
13000m*2500mm*3850mm |
Tare weight |
7700Kg |
Total Volume(m3) |
50 m³ |
Tanker Body Material |
6mm aluminium alloy 5083 |
End Plate |
7mm aluminium alloy 5083 |
Manhole Cover |
stainless steel manhole ,diameter 500mm,two pieces |
Bottom Valve |
Aluminum API Pneumatic Bottom Valve(DN100), one pieces |
Discharging Valve |
aluminium alloy ball valve 4 inch ,2 pieces |
Compartments |
1 pieces |
Discharging Pipe |
4”Rubber tube ,two pieces , six meters length |
Cat Walk |
As requirement |
Chassis | |
Main Beams |
Carbon steel Q345 |
Axle |
3 axles FUWA 13TON |
Landing Gear |
JOST C200T |
King Pin |
3.5 inch bolts type kin pin |
Suspension |
Mechanical suspension (America system ) |
Leaf Spring |
90mm(width)/13mm(thickness)/10pieces |
Pneumatic Braking System |
Vabco emergency valve,four double and two single chamber, one pieces air tanker . |
Rim |
9.00-22.5 13 pieces |
Tire |
12.00R22.5 Triangle Brand |
ABS |
With |
Fire extinguisher |
Two pieces 4 KG , |
Painting |
Main Beam ,suspension 2 coats of final paint ,tanker body no painting . |
Accessories |
One standard tool box ,steel |
