Specifications
1. Decreasing maintenance cost of equipments2. Reducing energy consumption of mill equipment
3. Improving operation rate
RK Wear Resistant Steel Pipe
RK-200 wear resistant composite pipe is produced by inner wall welding machine, the smallest pipe we can produce is diameter 80mm, thickness of the pipe wall is 5~30mm, the wear resistant pipe has dual metal characteristics, work layer is wear resistant and the base layer is flexible. Wear resistant layer contains high carbon and high chromium, also wear resistant layer with temperature resistance contains Mo, W, V, B, Nb, Ti and other alloy elements, the microstructure of wear resistant layer is eutectic +M7C3 carbide or complex carbide, the product with very good wearability and it can be applied under the circumstance of room temperature, high temperature, medium impact, low stress impact.
Application
Petroleum, chemical, pharmaceutical, printing and dyeing, food, brewing, energy and environmental protection, fertilizer and paper making, water and fire control, etc.
The corrosion resistant steel pipe we produced is a better substitute of stainless steel pipe, copper pipe or other kind of metal resistant pipe.
Specifications
The outer layer is Q235 seamless steel pipe, inner layer is stainless steel tube
Diameter can approach 80mm
Thickness: 5-30mm (can be customized)
| Name | RK Anti Wear Steel Pipe |
| Brand | RK |
| Color | brown |
| Diameter | ≥80mm(can be customized) |
| Thickness of wear resistant layer | as customer's require |
| Thickness of pipe wall | 5-30mm |
| Length | can be customized |
| Hardness | HRC57-62 |
| Standard | DIN,GB |
| Certificates | ISO9001:2000 |
| Specifications (base layer+wear resistant layer) |
5+3,6+3,8+3,5+4,6+4,8+4,10+4,6+5,8+5,10+5, 15+5,20+5,6+6,8+6,10+6,20+6,8+8,10+8,10+10, 15+10,20+10 |
| Model number | steel plate Q235 |
| Grade | first class |
| Applications | concrete industry,metallurgy,fan industry,coal industry,mining machinery,construction machinery,etc. |
| Payment terms | L/C,TT,D/P,Western union |
| Delivery time | 15 days after receipt of L/C or advanced payment |
| Trade terms | FOB,CIF,EXW,etc |
| Port | Shanghai |
