Specifications
1. Decreasing maintenance cost of equipments2. Reducing energy consumption of mill equipment
3. Improving operation rate
Products
Why our price is more expensive than ordinary steel?
Wear resistance seamless steel pipeis the newest high level wear resistant pipe in the world and it is developed by abrasion resistance pipe manufacturers --Zhangjiagang Runkun Wear Resistant Material Co., Limited. The base layer is Q235 metal and it is lined with chrome carbide alloy materials.
What advantages of our pipe?
1. The wear resistance is 20 to 25 times better than low carbon steel,8 to 12 times better than stainless and high manganese steel,1.5 times better than high carbon or high chromium wear resistant steel.
2. High temperature resistance. Our pipe still maintain abrasive resistance in high temperature 1000 degrees.
Chemical composition,mechanical properties and metallographic examination
C |
Si |
Mn |
Cr |
other |
4.0~5.5 |
0.5~1.5 |
0.5~2.5 |
24.0~30.0 |
less than 2.0 |
HRC 55-60
HRC 61-65
Specifications
| Name | Chromed square steel tubes |
| Brand | RK |
| Color | brown |
| Diameter | as customer's require |
| Thickness of wear resistant layer | as customer's require |
| Thickness of pipe wall | 5-30mm |
| Length | can be customized |
| Hardness | HRC57-62 |
| Standard | DIN,GB |
| Certificates | ISO9001:2000 |
| Specifications (base layer+wear resistant layer) |
5+3,6+3,8+3,5+4,6+4,8+4,10+4,6+5,8+5,10+5, 15+5,20+5,6+6,8+6,10+6,20+6,8+8,10+8,10+10, 15+10,20+10 |
| Model number | steel plate Q235 |
| Grade | first class |
| Applications | concrete industry,metallurgy,fan industry,coal industry,mining machinery,construction machinery,etc. |
| Payment terms | L/C,TT,D/P,Western union |
| Delivery time | 15 days after receipt of L/C or advanced payment |
| Trade terms | FOB,CIF,EXW,etc |
| Port | shanghai |
Processing Method
In the inner or external wall of general steel pipe (diameter 80mm above), with wear resistant pipe welding machine directly clad wear resistant layer of high carbon high chromium.
Inner wall welding machine
