Help CenterCE UL Approved Fused Luminaire Push WireTerminal Connector
Related Products
-
Ballast Connectors Terminal Block 2 PoleUS$ 0.01 - 0.35MOQ: 1000 Pieces -
Cable Crimp Cap Cloes-End Wire Connectors End Terminal Factory SupplyUS$ 0.01 - 1MOQ: 10000 Pieces
-
High Temp. Wire Connectors End Terminal Cable CrimpUS$ 0.01 - 1MOQ: 10000 Pieces
-
Yuyao Sineyi UL Approved Terminal Block 3 Poles Factory SupplyUS$ 0.01 - 1MOQ: 1000 Pieces
-
Terminal Block 12poles Factory SupplyUS$ 0.1 - 1MOQ: 1000 Pieces
Material:Nylon 66,UL 94V2, Natural
Housing:94V-2 Level 94V-2 Grade
Insert: Brass, Nickel plated
Screw: M3*6 Yellow chromated
Earth screw:M3*14 Yellow chromated
Voltage/Ampere(IEC)
Terminal Strip: 400V/15A
Fused Carrier: 250V/6.3A
Voltage/Ampere(UL)
Terminal Strip: 200V/15A
Fused Carrier: 200V/10A
Temperature
Working Temperature:-40°C to 100°C
140 °C
Wire:14AWG
Packaging:
540-1GWP 100*10 per/ctn
540-2GWP 70*10 per/ctn
540-3GWP 50*10 per/ctn
540-4GWP 40*10 per/ctn
540-5GWP 40*10 per/ctn
Terminal strip with fuse-carrier
Dovetail for different terminal combinations
For 50*20 mm fuse
Earth-screw option
IP20 finger protection
Anti-rotation spigot as option
1,2,3,4and 5 poles available
Color-housing in grey, fuse carrier in black
