Home > Products > XCMG machine > XCMG 35 Ton P&h Truck Crane QY35K5
XCMG 35 Ton P&h Truck Crane QY35K5
- Lianyuangang
- T/T
You May Like
Product Details
| Condition | New | Application | Material handling | |
| Rated Loading Capacity | 35 ton | Rated Lifting Moment | 1200 kN.m | |
| Max. Lifting Load | 35 ton | Max. Lifting Height | 54.6m | |
| Span | 6m | Place of Origin | Jiangsu, China | |
| Brand Name | XCMG | Model Number | QY35K5 | |
| Certification | ISO9001 | Warranty | 1 Year | |
| After-sales Service Provided | Overseas service center available |
Product Description
Main Information
Max.lifting capacity:35t
Fully extended boom: 39.6m
Fully extend boom+jib:54.6m
Detail Specification of XCMG 35 ton p&h truck crane QY35K5
Dimension | Unit | QY35K5 |
Overall length | mm | 12620 |
Overall width | mm | 2500 |
Overall height | mm | 3350 |
Weight |
|
|
Total weight in travel | kg | 36930 |
Front axle load | kg | 12330 |
Rear axle load | kg | 24600 |
Power |
|
|
Engine model |
| SC9DK320Q3 |
Engine rated power | kW/(r/min) | 235 / 2200 |
Engine rated torque | N.m/(r/min) | 1250 / 1400 |
Travel |
|
|
Max. travel speed | km/h | 75 |
Min. turning diameter | m | 19.5 |
Min. ground clearance | mm | 260 |
Approach angle | ° | 17 |
Departure angle | ° | 15.7 |
Max. grade ability | % | 40 |
Fuel consumption for 100km | L | 30 |
Main performance |
|
|
Max. rated total lifting capacity | t | 35 |
Min. rated working radius | mm | 3000 |
Turning radius at turntable tail | m | 3.055 |
Max. lifting torque | kN.m | 1200 |
Base boom | m | 10.5 |
Fully extended boom | m | 39.6 |
Fully extended boom+ jib | m | 54.6 |
Longitudinal outrigger span | m | 5.35 |
Lateral outrigger span | m | 6 |
Working speed |
|
|
Boom luffing time | s | 68 |
Boom full extension time | s | ≤155 |
Max. swing speed | r/min | ≥2.5 |
Max. speed of main winch (single rope) | m/min | ≥130 |
Max. speed of aux. winch (single rope) | m/min | ≥130 |
