Rubber type shot blasting machine:
The machine adopts endless rubber apron to form a special barrel,to make the work pieces tumber continuously during shot blasting process.It is mainly used in forging work pieces and metal work pieces.
GN Mass-produced components,which can be tumbled,are ideal for processing in tumble belt batch maxhines,no matter what materials they are made form.Anything form small,delicate plastic parts to large,forged components,can be finished to the highest standard.
There are pictures of rubber type shot blasting machine about 3GN,8GN, 8GN-5R , 15GN .
3GN type product show 8GN type product show
8GN-5R 15GN
GN SERIES SHOT MACHINE PARAMETERS
| Mode | Effective volume | Feeding amount | Total Blasting Capacity | Total Power |
| 3GN | 705*800mm | 220Kg/12Kg | 7.5Kw/180Kg | 13.1Kw |
| 6GN-5R | 857*940mm | 363Kg/23Kg | 11Kw/240Kg | 19.2Kw |
| 8GN | 1100*1050mm | 700Kg/35Kg | 15Kw/270Kg | 23.2Kw |
| 8GN-5R | 1100*1050mm | 750Kg/35Kg | 15Kw/270Kg | 27.4Kw |
| 12GN | 1150*1050mm | 850Kg/80Kg | 18.5Kw/300Kg | 31.5Kw |
| 12GN-5R | 1150*1050mm | 750Kg/80Kg | 18.5Kw/300Kg | 34.4Kw |
| 15GN | 1292*1245mm | 1362Kg/227Kg | 22Kw/360Kg | 40.3Kw |
| 28GN | 1445*1778mm | 3500Kg/363Kg | 22Kw/720Kg | 73.5Kw |
The working principle of tracked Shotblast cleaning machine :
Add the specified amount of workpiece in the clean room, the machine starts, shot blasting machine, high-speed projectiles thrown into flow pill beam, uniformly blow on the surface of the work piece, so as to achieve the purpose of cleaning, reinforcement. Projectile and the sand thrown into ascension, machine, by hoist to separator for separation. Dust from the suction fan to in the dust filter, the clean air is discharged into the atmosphere, dust bag dust collecting box by the mechanical vibration into the bottom of dust collector, the user can be regularly cleaned, sand waste by waste pipe, the user can reuse. Pill sand mixture by reuse pipe back into the chamber body, to be separated again after use, clean the projectile by electromagnetic pellet feeding gate into the blast wheel thrown workpieces
THE PACKING:
Qingdao Foundry Machine Co., Ltd. is a specialized company in design and production of: Main production dust collector, dust collector, single bag dust collector, filter bag and other various dedusting accessories products
Company technical cengcengbaguan, using computer testing equipment to ensure each product qualified, unqualified products put an end to enter the market of environmental protection, the company also recognized by the vast number of old and new customers, products sold at home and abroad!
The company products are widely used in coal-fired power plants, metallurgy, mining, building materials, casting, chemical machinery, food, tobacco, asphalt cement (including biological boiler), mechanical processing, boiler etc, and realizes the design - production - installation and debugging, technical training services.
1.Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in time.
3. Customized design is available.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Special discount and protection of sales are provided to our distributor.
6. Professional factory: We are manufacturer, specializing in producing all kinds of Shot Blasting Machine & Molding Machine & Core Shooting Machine for more than 40 years, competitive with good quality.
7. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature.
Customer Inspection
Other kinds of shot blasting machines in our company:
Q69 Series Roller Conveyor Type Shot Blasting Machine
KSB Series Hook Type Shot Blasting Machine
Q37 Series Shot Blasting Machine For Engineering Machinery
Q311 Series Drum Type Shot Blasting Machine
Q26/Q36 Series Flatcar Shot (Spray) Type Cleaning Machine
Q76 Series Trolley Type Shot Blasting Machine
Q38 Continuous Pendant Chain Type Shot Blasting Machine
Q48 Step-By-Step Pendant Chain Type Shot Blasting Machine
Q58 Changeable Chain Type Shot Blasting Machine
ZJ0 Series Rotary Table Shot Blasting Machine
ZJ02 Series Spring Shot Blasting Machine
ZJ18 Series Wheel Roller Shot Blasting Machine
QGW Series Steel Tube Outer Wall Shot Blasting Machine
QGN Series Pipe Inwall Shot Blasting Machine
GN Series Belt Type Shot Blasting Machine
Q32 Series Apron Type Shot Blasting Machine
Q35 Series Turntable Type Shot Blasting Machine
QWD Series Wire Mesh Belt Type Shot Blasting Machine
QSHBSeries Rotary Hook Type Shot Blasting Machine
QX Series Wire Rod Shot Blasting Machine
QM Series Special Shot Blasting Machine For Anchor Chain
RE Series Shot Peening Machine For Strengthening For Mill Roll
CND Series Inclined Drum Shot Blasting Machine
SHB Series Turntable Shot Blasting Machine
Ql Series Squirrel-Cage Type Shot Blasting Machine
ZJ076 Series Leaf Spring Shot Peening Machine For Strengthening
SCC Series Spring Shot Peening Machine For Strengthening
SNC Series Bar Shot Blasting Machine
