Precision Alloy/expanding Alloy/magnetic Alloy

Precision Alloy/expanding Alloy/magnetic Alloy thumbnail-1
Precision Alloy/expanding Alloy/magnetic Alloy photo-1
Negotiable MOQ: 100 Kilograms (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
longxin-alloy
Model Number:
008
Contact Supplier Request Quote Chat Now
Danyang Longxin Metal Alloy Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name longxin-alloy
Model Number 008
Application memory element,compensating element,inductance element
Shape bar/sheet/ribbon/plate/strip/wire/tube
Material Ni-Cr-Fe
Dimensions according to clients' requirement
Chemical Composition Ni-Cr-Fe

Specifications

Precision Alloy/expanding alloy/magnetic alloy
1.ISO9001 certification;
2.fine after-sale services
3.small order accepted;





Precision Alloy/expanding alloy/magnetic alloy





Precision alloy

Brand(label):

1.Soft magnetic alloy:

high permeability alloy:1J79,1J85,1J86,1J116,1J117,1J36

High permeability and saturation induction alloy:1J50,1J46,1J54

Compensator alloy:1J38.1J30,1J31,1J32

High hardness,high resisitance,high magnetic conductibility alloy:1J87,1J89,1J88

Magnetic head material:1J75,1J77C,1J79C,1J85C,1J87C,1J92,1J93,1J94,1J95

Property:magnetic property, high magnetic conductibility,high resisitance,

High hardness,high saturation induction,ect.

Function:memory element,compensating element,inductance element for

Transformer, magnetic amplifier.isolating flake,magentic head for

recorder, Movie machine, Checking attendance machine.iron core for Transformer,choke,pulse transformer,relay,and magnetic amplifier.

2.Expanding alloy

fernico glass sealing alloy:4J29,4J44,4J49

fernico sealing alloy:4J33,4J34,4J32

Iron-nickel glass sealing alloy: 4J42,4J30

Iron-nickel-chromiun glass sealing alloy:4J6

Iron-chromiun glass sealing alloy:4J28

Low-expandsion alloy:4J36

Other:4J50,4J58

Property:dense oxide film,strong anti-oxidability,good plasticity,

low expansion coefficient,abradability.

Function:fusion bonding,welding,machining,sealing.

Specs:thickness 0.08mm~3mm   width 5mm~250mm

Grade C S P Mn Si Ni Cr Co Mo Cu Al Nb Fe other
1J30 max0.04 max0.02 max0.02 max0.4 max0.3 29.5~30.5             balance
1J31 max0.04 max0.02 max0.02 max0.4 max0.3 30.5~31.5             balance
1J32 max0.04 max0.02 max0.02 max0.4 max0.3 31.5~32.5             balance
1J36 max0.03 max0.02 max0.02 max0.6 max0.2 35.0~37.0             balance
1J38 max0.05 max0.02 max0.02 0.3~0.6 0.15~0.3 37.5~38.5 12.5~13.5           balance
1J50 max0.03 max0.02 max0.02 0.3~0.6 0.15~0.3 49.0~50.5       max0.2     balance
1J46 max0.03 max0.02 max0.02 0.6~1.1 0.15~0.3 49.0~50.5       max0.2     balance
1J54 max0.03 max0.02 max0.02 0.3~0.6 1.1~1.4 49.5~51.0 3.8~4.2     max0.2     balance
1J79 max0.03 max0.02 max0.02 0.6~1.1 0.3~0.5 78.5~80.0     3.8~4.1 max0.2     balance
1J85 max0.03 max0.02 max0.02 0.3~0.6 0.15~0.3 79.0~81.0     4.8~5.2 max0.2     balance
1J86 max0.03 max0.02 max0.02 max1.0 max0.3 80.5~81.5     5.8~6.2       balance
1J87 max0.03 max0.02 max0.02 0.3~0.6 max0.3 78.5~80.5     1.6~2.2     6.5~7.5 balance
1J88 max0.03 max0.02 max0.02 max0.6 max0.3 79.5~80.5           7.5~9.0 balance
1J89 max0.03 max0.02 max0.02 0.5~1.0 max0.3 78.5~80.5     3.5~4.5     3.0~3.6 balance Ti:1.8~2.8
1J116 max0.03 max0.02 max0.02 max0.6 max0.2   15.5~16.5           balance
1J117 max0.03 max0.02 max0.02 0.3~0.7 max0.15 0.50~0.70 17.0~18.5           balance Ti:0.3~0.7
4J06 max0.05 max0.02 max0.02 max0.25 max0.3 41.5~42.5 5.5~6.3       max0.2   balance
4J28 max0.12 max0.02 max0.02 max1.00 max0.7 max0.5 27.0~29.0           balance N:max0.2
4J29 max0.03 max0.02 max0.02 max0.5 max0.3 28.5~29.5 max0.2 16.8~17.8 max0.2 max0.2     balance
4J33 max0.05 max0.02 max0.02 max0.5 max0.3 32.1~33.6   14.0~15.2         balance
4J34 max0.05 max0.02 max0.02 max0.5 max0.3 28.5~29.5   19.5~20.5         balance
4J36 max0.05 max0.02 max0.02 0.2~0.6 max0.3 35.0~37.0             balance
4J32 max0.05 max0.02 max0.02 0.2~0.6 max0.2 31.5~33.0   3.2~4.2   0.4~0.8     balance
4J42 max0.05 max0.02 max0.02 max0.8 max0.3 41.5~42.5   max0.1     max0.1   balance
4J44 max0.3 max0.02 max0.02 max0.5 max0.3 34.2~35.2 max0.2 8.5~9.5 max0.2 max0.2     balance
4J49 max0.05 max0.02 max0.02 max0.4 max0.3 46.0~48.0 5.0~6.0           balance B:max0.02
4J50 max0.05 max0.02 max0.02 max0.8 max0.3 49.5~50.5         max0.1   balance
4J58 max0.03 max0.015 max0.6 max0.25 57.5~59.5               balance
1J75 max0.03 max0.02 max0.02 0.5~1.0 max0.3 74.0~76.0     1.5~2.0 5.0~7.0     balance W:1.0~1.5
1J77C max0.03 max0.02 max0.02 max0.7 max0.3 76.5~78.0     3.5~4.5 3.8~5.3     balance
1J79C max0.03 max0.02 max0.02 0.7~1.2 0.3~0.6 78.0~81.5     3.7~4.5       balance
1J85C max0.03 max0.02 max0.02 0.3~0.7 0.15~0.30 80.0~81.5     5.0~6.0       balance
1J87C max0.03 max0.02 max0.02 0.3~0.6 max0.3 80.0~81.5     1.0~2.0     4.0~5.5 balance
1J92 max0.03 max0.02 max0.02 max0.6 max0.3 80.1~81.1     1.0~1.5     3.0~4.0 balance W:1.0~1.5
1J93 max0.03 max0.02 max0.02 0.3~0.6 max0.3 80.5~81.5     3.0~4.0     3.0~4.5 balance
1J94 max0.03 max0.02 max0.02 0.3~0.6 max0.3 79.5~81.0 0.3~0.7   4.5~5.0 1.5~2.5   0.6~1.0 balance
1J95 max0.03 max0.02 max0.02   2.8~3.3 83.0~84.0     1.2~1.6     0.4~0.6 balance



Specification: Plate, sheet, strip, rod, bar, wire, tube



We are looking forward to cooperating with you!
