Small Automatic Paste Vertical Filling Packing Machine

Features:

1.      Automatic liquid packing machine can finish the process like conveying bag, bag making, filling, weighing, sealing, cutting, counting, lot number, etc.

2.      Bilingual display screen control system, stainless steel cabinet. Set up the required data(include filling ,weighing, bag size, etc) in the various settings, the control system automatic optimization match with all the program so that achieve the best packing speed precisely.

3.      Stepper Motor control, this system has the advantage of precise, needless to adjust the other parts, and acoup sur.

4.      It has color system controller, so that can get the complete trade mark design.

5.      Suitable for the complex film and tin foil and other packing material. Fine packaging performance, low noise, clear sealing texture and strong sealing performance.

Applications:

Automatic liquid packing machine of pharmacy, food, household chemicals ,pesticides and the plastic products and other troche or grain materials, such as shampoo, body foam, oil grease, cosmetics, pharmacy, chemical fertilizer, seasoning oil, chile sauce ,ketchup ,etc.

Optional Equipment:

Thermal Printer

Conversion from trilateral seal to quadrilateral seal

Venting Device

Easy-to-Tear-Knife-Device

Flat cutter, Tooth cutter, continuous point cutter

Technical data:

--Packing speed:30-60bag/min (PS: pls be noted that this is speed not weightJ)

--Measuring Scope:1-120ml (more than 70 gram)

--Bag Size:(L)40-200,(W)40-110mm

--Film Width:220mm

--Sealing Type:trilateral seal or quadrilateral seal or back sealed

--Power:1350W

--Net Weight:230kg

--Voltage:220V,380V/50Hz

--Packing Material:paper/PE, Polyester/aluminum –foil/PE, nylon/polyethylene, tea filter paper, etc.

--Overall Size:L800×W800×H1650mm
