Home > Packaging & Printing > Packing Machinery > Filling Machine > FF4-1000 Milk Bottle Filling Machine
FF4-1000 Milk Bottle Filling Machine
US$ 600 - 2,800
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Chemical, Commodity, Food, Other, Medical, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical
Packaging Type:
Bags, Barrel, Bottles, Cans, Pouch, Stand-up Pouch
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
FF4-100 Paste Cream Filling MachineUS$ 600 - 2,800MOQ: 1 Set -
FF5-200 Filling Machine Electric CigaretteUS$ 900 - 1,800MOQ: 1 Set
-
FF5-100 Electric Driven E-liquid Filling MachineUS$ 900 - 1,800MOQ: 1 Set
-
FF5-100 Pedal Perfume Cream Filling MachineUS$ 1,080 - 1,700MOQ: 1 Set
-
A03 E-liquid Filling MachineUS$ 178 - 250MOQ: 1 Set
Condition
New
Application
Beverage, Chemical, Commodity, Food, Other, Medical, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical
Packaging Type
Bags, Barrel, Bottles, Cans, Pouch, Stand-up Pouch
Packaging Material
Glass, Metal, Plastic
Automatic Grade
Semi-Automatic
Driven Type
Pneumatic
Voltage
220v/50Hz or 110v/60Hz(Optional)
Power
0kw
Place of Origin
Zhejiang, China
Brand Name
T&D
Model Number
FF4-1000
Dimension(L*W*H)
490*455*1552mm
Weight
60kg
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
milk bottle filling machine
FF4-1000
Product Description
Features
- Adopt Taiwan Airtac pneumatic components, full pneumatic drive does not need electrical power, simple operation, high filling precision;
- Using 304 stainless steel construction of material contact parts, optional 304 or 316 stinless steel;
- Stainless steel valve system design;
- Can be operated by foot pedal or by automatic timer, could transfer between semi-automatic and automatic;
- Filling volume, filling speed can be adjustable, bottom close positive shutoff nozzles ensure drip free operations;
- Extremely easy to chean and maintain;
- Quick release nozzle and feed pipe;
- Optional type 10-100ml 20-200ml 30-300ml 50-500ml 100-1000ml;
- Conform to GMP;
Application:
- They are most commonly applicable for pharmaceutics, daily chemicals, foodstuffs, cosmetics, pesticides and other industrials.
- Typical application: Use for filling liquid and paste material, more suitable for high viscous products. Such as mineral water, cooking oils, juice, detergent, sauce, salad, butter & margarine, ketchup, jams, cream, honey, shampoos etc.
- Suitable for various packing such as bottle, jar, can, cup, bag, barrels,etc.
Note:
1,we can customize the special size according to customer's demands.
2,The machine disposition may make the choice.
Parameters
| Model | FF4-100 | FF4-200 | FF4-300 | FF4-500 | FF4-1000 |
| Filling range | 5-100ml | 10-200ml | 20-300ml | 50-500ml | 100-1000ml |
| Air pressure range | 0.4~0.6mpa | ||||
| Filling speed | 30-60pcs/min | ||||
| Filling precision | 1% | ||||
| Voltage | 220v/50Hz or 110v/60Hz(Optional) | ||||
| Dimension | 490*455*1552mm | ||||
| Weight | 60kg | ||||
Details
Samples
Company show
Our Services
We are professional manufactory, produce in hot stamping machine, heat transfer machine, filling machine, packaging machine, etc. And we produces many types of this machine. We can provide OME/ODM service, we base our business on offering products and services that people want and need, as well as continuing to develop an innovative approach to marketing.
Packaging & Shipping
All the products before delivery should be tested by assemble&debugging engineer, wiped up and cleaned,then wrapped by stretch film to protect it from moist. The precision part need to flexible package. In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory.
All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading&uploading, the upward mark will be posted on the wooden case.
FAQ
1. Each machine is manufactured by our professional staff production and manufacturing;
2. Production process through strict supervision and review, use a lot of the high parts at home and abroad, to ensure good quality;
3. Use a lot of 304 stainless steel to ensure food safety, can choose the material contact parts use 304 stainless steel or whole machine use;
4. The warranty time is one year. Under warranty, if is according to the introduction of the description of the use of case, any damage to the product, we will provide free maintenance service or free replacement, but need customer pay for the freight from China to local place. If you need our engineers to help, will be paid by customer of travel back and forth.
5. Outside the warranty period, we continue to provide lifetime maintenance services.
