Weichai Motor Marine WD615C series
Specifications
1.Weichai boat diesel engine
2. 6 cylinder marine engine
3. Chinese famous marine engine
4. engine for ships and yacht
5.power range from 110 to 220kW
6.speed range from 1500 to 2100rpm
7.high reliability low smokepower
8.CE ISO9001:2000
| Model | WD615.67C-10 motor marine |
| Rated output(kw) | 176 |
| Rated speed(r/min) | 1800 |
| Type | Water cooled, inline, 4-stroke, dry cylinder liner, direct injection, turbocharged, turbocharged inter-cooled |
| Num of cylinders | 6 |
| Bore/Stroke(mm) | 126/130 |
| Fuel consumption(g/kW.h) | ≤198 |
| Oil/fuel consumption(g/kW.h) | ≤0.5 |
| Stable governing rate(%) | ≤8(mechanical) |
| Starting method | Electrical starting |
| Idle speed(r/min) | 600±50 |
| Smoke(Rb) | ≤1.2 |
| Displacement(L) | 9.726 |
| (dB(A)) Noise | ≤108 |
| Emission | Euro II |
| Crankshaft rotation direction | counter clockwise(face to flywheel end) |
| Gearbox Model | WHG 135 |
| Ratio | 5:1 or 4.5:1 or others |
WD615 Sereis Motor Marine | |||||||
Type |
cylinder- |
Bore/stroke |
Displacement |
Rated output |
Rated speed |
Suit for Application |
|
WD615.61C |
6 |
126/130 |
9.726 |
140 |
1800 |
fishing ship, transport ship |
|
WD615.67C |
6 |
126/130 |
9.726 |
176 |
1800 |
fishing ship, transport ship |
|
WD615.68C |
6 |
126/130 |
9.726 |
205 |
2100 |
transport ship,speed boat |
|
WD615.46C |
6 |
126/130 |
9.726 |
220 |
2100 |
transport ship,speed boat |
|
WD615C-21 |
6 |
126/130 |
9.726 |
190 |
1500 |
fishing ship, transport ship |
|
WD615C-22 |
6 |
126/130 |
9.726 |
176 |
1500 |
fishing ship, transport ship |
|
WD615C-23 |
6 |
126/130 |
9.726 |
160 |
1500 |
fishing ship, transport ship |
|
WD615C-24 |
6 |
126/130 |
9.726 |
140 |
1500 |
fishing ship, transport ship |
|
WD615.61C-2 |
6 |
126/130 |
9.726 |
147 |
2100 |
transport ship,speed boat |
|
WD615.61C-6 |
6 |
126/130 |
9.726 |
110 |
1800 |
fishing ship, transport ship |
|
WD615.67C-15A |
6 |
126/130 |
9.726 |
136 |
1500 |
fishing ship, transport ship |
|
WD615.67C-20 |
6 |
126/130 |
9.726 |
180 |
2000 |
fishing ship, transport ship |
|
WD615.61C-2A |
6 |
126/130 |
9.726 |
121 |
2100 |
transport ship,speed boat |
|
WD615.61C-10A |
6 |
126/130 |
9.726 |
110 |
1800 |
fishing ship, transport ship |
|
WD615.68C-18 |
6 |
126/130 |
9.726 |
160 |
1800 |
fishing ship, transport ship |
|
WD615.68C-2 |
6 |
126/130 |
9.726 |
190 |
1800 |
fishing ship, transport ship |
|
WD615.68C-19 |
6 |
126/130 |
9.726 |
192 |
1900 |
fishing ship, transport ship |
|
WD615.61C-15 |
6 |
126/130 |
9.726 |
110 |
1500 |
fishing ship, transport ship |
|
Chinese motor marine dimension
