Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > Argox A-3140 Desktop Thermal Transfer Printer
Argox A-3140 Desktop Thermal Transfer Printer
Negotiable
MOQ: 10 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Other
Use:
Barcode Printer
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Argox F1 Industrial Barcode PrinterNegotiableMOQ: 10 Units -
Zebra TLP2844 Label PrinterNegotiableMOQ: 10 Units
-
Thermal Printer Argox OS214 PlusNegotiableMOQ: 10 Units
-
Barcode Printer Argox OS-214 PlusNegotiableMOQ: 10 Units
-
Laser Wireless Barcode Scanner With MemoryUS$ 100 - 150MOQ: 10 Sets
Products Status
Stock
Type
Other
Use
Barcode Printer
Interface Type
Other
Max. Resolution
300dpi
Brand Name
ARGOX
Model Number
A-3140
Specifications
The A-3140 desktop thermal transfer printer offers 300dpi resolution and is ideal for printing high quality textThe A-3140 desktop thermal transfer printer offers 300dpi resolution and is ideal for printing high quality text and graphic labels such as for logos, small items such as jewelry, or for information labels. Printing up to a rapid four inches per second, the A-3140 has a 32-bit microprocessor, as well as 8M Flash and 8M DRAM internal memory for high print quality. Easily integrating with your current system, the A-3140 connects through standard serial ports and a USB interface. You can load a maximum 5" OD media roll and a see-through window lets you see when it’s time to reload. Four auto-calibration modes and reflective and transmissive sensors handle a broad range of media for printing up to 50-inches in length. Barcode support includes 1D/GS1 Data bar, 2D/Composite codes and QR barcodes. For high quality printing, the user-friendly A-3140 provides outstanding and cost-effective performance.
1. 300dpi print resolution for high quality printing of text and graphics
2. 8M Flash and 8M DRAM memory for high print quality
3. 32-bit CPU for up to 4ips printing speed
4. No ribbon wrinkle with centralized thermal print head
5. RS-232 and USB interfaces
6. Reflective and transmissive movable sensors, and fixed center transmissive sensor
7. Large 5-inch OD media capacity
8. Easy installation of media and ribbon
9. Leverages Argox existing controller technology
10. Supports 1D/GS1 Data bar, 2D/Composite codes and QR barcodes, and more
11. Options include: Cutter, Peeler, Media Stacker, RTC card and Argokee standalone keyboard
Printing method |
Direct Thermal & Thermal Transfer |
||
Printing resolution |
300dpi(12 dots/mm) |
||
Printing Speed |
1~4ips(25~102mm/s) |
||
Printing Length |
Max 50 |
||
Printing Width |
MAX 4.1 |
||
Memory |
8MB DRAM (5MB user available) 8MB Flash ROM (6MB user available) |
||
CPU Type |
32 bit RISC microproceessor |
||
Sensors |
Media gap & black line Reflective sensor x 1 (Movable) & Transmissive semsor x 1(Movable) Center Fixed transmissive / Head open switch / Ribbon end sensor |
||
Operation Interface |
LED Indicator(Power/Ready)x2, Button(Feed)x1 |
||
Communication Interface |
RS-232, USB(2.0) |
Software - Label editing |
Windows Driver (Win 2000/XP/Vista/Windows 7), BarTender |
||
Software - Utility |
Printer Utilit, Font Utility |
||
Media Type |
Roll-feed, die cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper and fabric label |
||
Media |
Max Width: 4.25(108mm) Min Width:1(25.4mm) |
||
Ribbon |
Ribbon Width: 1”~4” Ribbon roll – max OD: 1.45”(37mm) Ribbon Length: max 100m Core size – ID: 0.5”(13mm) with notch Wax, Wax/Resin, Resin (Ribbon Wound Ink-Side Out) |
||
Dimensions |
W201mm x H179mm x L250mm |
||
Weight |
2.2kgs |
