Features
1,Wireless + cable dual two-mode laser barcode scanner, patent technology.
2,Supports Windows + android+ iOS three operating system wireless laser barcode scanner.
3,With real infrared sense wireless laser bar code scanner.
4,Substantial taobao customers recognized the fastest wireless laser barcode scanner.
5, longest Standby time wireless barcode scanner ;Large capacity lithium electricity, ultra-low power consumption power management technology, work for more than a week after charge once.
6,Wireless bluetooth technology, the most safe green barcode scanner with no radiation to human body .
Technical parameters
PHYSICAL CHARACTERISTICS | ||
Material |
ABS+TPU |
|
Size |
Length 167mm*Width 70mm* Height 85.5mm |
|
Color |
White |
|
Power supply |
Built-in rechargeable 1600mA.H lithium battery |
|
Weight |
150g(With battery) |
|
PERFORMANCE CHARACTRISTICS | ||
Bluetooth |
Bluetooth class 2.0, Version +EDR |
|
Processor |
ARM 7 72MHz |
|
EEPROM |
128K, can store thousands of barcodes |
|
Interfaces Supported |
Multiple Interface with: USB, RS232, PS2 Keyboard |
|
Support OS |
Microsoft Windows XP/7.0/8.0, Mobile6/Wince, Android, IOS. |
|
Interfaces Supported |
SPP, HID |
|
Light Source (Laser) |
Laser LED 650+/-20nm |
|
Sensor |
2500 pixels |
|
Decode Capability |
Codabar, Code 11, Code 93, MSI, Code 128, UCC/EAN-128, Code 39, EAN-8, EAN-13, UPC-A, ISBN, Industrial 25, Interleaved 25, Standard 25, 2/5 Matrix |
|
Resolution |
5mil |
|
Nominal Working Distance |
6~30cm |
|
Decode Rate |
200 decodes per second |
|
Scan width |
30mm=Scanner Window |
|
Decode mode |
Single-Line Aiming |
|
Scan mode |
Auto off mode / Manual mode |
|
Print Contrast Minimum |
30% |
|
Scan angles |
Roll 30° Pitch 75° Yaw65° |
|
Cylinder Horizontal Scan |
Diameter 35mm |
|
Indication |
Beeper, LED |
|
Radio Range |
10m Visual range |
|
POWER | ||
Voltage |
DC 5V |
|
standby Current |
35mA |
|
Operating current |
60mA |
|
USER ENVIRONMENT | ||
Operating Temp. |
0 to 50. °C / 32 to 122°F |
|
Storage Temp. |
0 to 50. °C / 32 to 122°F |
|
Operating Humidity |
20-85% ( non-condensing ) |
|
Storage Humidity |
20-85% ( non-condensing ) |
|
Drop Specifications |
Free fall of 1.5m air drop |
|
Accessories |
Lithium battery, Charger., Data lines |
|
Packing instructions
YHD –CT10 standard listing: code bar scanner* 1 , manual*1, wireless receiver * 1, charging line * 1, leather box * 1.
