Specifications
1.Application: Misting/Cooling System2.Orifice diameter: 0.1-0.5m
3.Thread size:10/24,12/24 UNC
4.Spray pattern:Full Cone
—Slip Clock Fittings—Quick Connector
1.Mist Nozzles Application:
Fog Cooling System,Humidifying,Misting, Mist Maker,Dust Control
2.Accessory with:
Filter and anti-drip,Ceramic orifice
3.Thread Size:
10/24,12/24 UNC,1/4'',1/8''
4.Orifice Diameter:
0.1mm-0.5mm
5.Nozzles Design Features:
Ceramic insert
Outstanding atomization
Drip-free performance
50 micron polypropylene filter
Safety wire hole available
Minimum operating pressure 100 psi (7 bar)
6.Mist nozzle's spray Characteristics:
Mist at low pressure; fog nozzles work at high pressure
7.Spray pattern:
Cone-shaped Fog
8.Technical data sheet for Mist nozzles:
Part No. | Size dia./¢ | Thread | Pressure | Flow Rate |
FGC10 | 0.10mm/0.004" | 10/24,12/24,3/16" | 20-70bar | 0.016-0.040L/Min |
FGC15 | 0.15mm/0.006" | 10/24,12/24,3/16" | 20-70bar | 0.029-0.046L/Min |
FGC20 | 0.20mm/0.008" | 10/24,12/24,3/16" | 20-70bar | 0.049-0.089L/Min |
FGC30 | 0.30mm/0.012" | 10/24,12/24,3/16" | 15-70bar | 0.065-0.145L/Min |
FGC40 | 0.40mm/0.016" | 10/24,12/24,3/16" | 7-70bar | 0.056-0.178L/Min |
FGC50 | 0.50mm/0.02" | 10/24,12/24,3/16" | 7-70bar | 0.077-0.248L/Min |
