China Wholesale Merchandise Dichroic Lighting Filters
- T/T
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | kingki | |
| Model Number | 700nm | Size | 3mm-460*460mm | |
| Material | k9 etc. | Use | instrumetation |
Product Description
China wholesale merchandise dichroic lighting filters
Second, the dichroic mirror (color separation filter) can be used to isolate a specific range of the visible spectrum, a small amount of color used in the addition and photocopier in the color balance.
The type of filters in the incident beam can be divided into two or more beam applications also play a big role.
Applications
Laser light, stage computer lights, moving head light, color wheel, beam splitter optics, laser systems
Material:
K9 glass, quartz glass, etc.
Other arbitrary size can be customized according to customer demand, the maximum size 55 ×55mm
Second, add color to the dichroic mirror is generally divided into type, subtractive and reflective type of three.
Hyperchromic type, subtractive model is widely used in laser lights, computer lights, lighting and image processing, with the general use of incident angle 0 °
Hyperchromic type | Index |
505 | Tave>90%@400-585nm,Tave<1%@525-700nm |
540 | Tave<1%@400-580nm & 600-700nm,Tave>80%@560- 580nm |
585 | Tave<1%@400-565nm,Tave>90%@605-700nm |
Specification | 3×3~55×55mm
|
Subtractive-type | Index |
520 | Tave<1%@400-500nm,Tave>90%@540-700nm |
540 | Tave>80%@400-470nm & 610-700nm,Tave<1%@500-580nm |
590 | Tave>90%@400-570nm,Tave<1%@610-700nm |
Specification | 3×3~55×55mm
|
Reflective optical system was widely used as a beam splitter, such as band pass filter and fluorescence PCR with the use of general use incident angle of 45 °
Reflective | Index |
416 | R>98%@291-391nm,T>90%@441-541nm |
515 | R>98%@390-490nm,T>90%@540-640nm |
525 | R>98%@400-500nm,T>90%@550-650nm |
550 | R>98%@425-525nm,T>90%@575-675nm |
570 | R>98%@445-545nm,T>90%@595-695nm |
615 | R>98%@490-590nm,T>90%@640-740nm |
Specification | 3×3-55×55mm |
