China alunimium anodized/brass line Laser Diode Module,diode pumped laser module
Product descriptions of diode pumped laser module
Violet 405nm Laser Diode Modules
Elite could provide high quality 405nm laser diode module. Except the models listed below, several more options are available. Elite could also do customized new Blue Violet & Green Laser Diode Module.
405nm (Violet) 5mw ~ 120mw Dot & Line Laser Diode Module
Quick Details
- Place of Origin: Shaanxi, China (Mainland)
- Brand Name: ELITE
- Model Number: VB405D05VGx
- Wavelength: 405nm
- Material: alunimium anodized or brass
- Color: Brass or silver or black
- Beam type: dot, line, cross
- Type: Laser Diode
- Package Type: As customer request
- Certificated: FDA IEC SGS ISO9001-2008
Packaging & Delivery
Packaging Details: | One Unit packed with condense foam, Bulk into export cartons. |
Delivery Detail: | 10-20day depending on the QTY |
Specifications
11 years experience with manufacture and design
FDA IEC SGS ISO9001-2008
Low Consumption
High Reliability
LongLife Span
-Compact size
-SGS TUV assessed supplier
-Wide work temperature
-High reliability
Specifications
Items | Specifications | ||||||||
Spectral Range | Violet | Blue | Red | Infrared | |||||
Wavelength | 405nm | 450nm | 635nm | 650nm | 780nm | 808nm | 830nm | 850nm | 980nm |
LD power(mW) | 5- 50 | 5-60 | 5~180 | 5~150 | 5~200 | 50~5000 | 5-100 | 5~100 | 20~5000 |
Operating Current | 25~5000mA | ||||||||
Input Voltage | 2.6~5.5VDC | ||||||||
Operating Temp. | -10°C ~ 50°C | ||||||||
Storage Temp. | -40°C ~ 80°C | ||||||||
Power Stability | > 98% (@2.7 ~ 5.5VDC) | ||||||||
> 95% (@-10°C ~ 50°C) | |||||||||
MTTF | >10000 Hrs. | ||||||||
Circuit Protection | Static, Surge, and Reverse Polarity Protected | ||||||||
Case Material | Brass or Aluminum | ||||||||
Beam Pattern | Dot, Line ,Cross | ||||||||
Key Features
1, High quality industrial laser diode
2, APC driving circuit
3, Low cost
4, High reliability
5, Long Life
Application:
1. Industrial Instruments and Equipments
2. Wild Explore Instruments
3. Military Instruments and Equipments
4. Medical Instruments
Model | Wave Length | Aperture | Output | Divergence | Beam Size | Lens | Dimension |
VB405D05VG1 | 405nm | ¢4.5mm | <2.5mw | 0.1mrad | ¢5mm(@10m) | Optical Glass | ¢10x35mm |
VB405D05VG2 | 405nm | ¢5.0mm | <3.5mw | 0.2mrad | ¢4x8mm(@10m) | Optical Glass | ¢12x40mm |
VB405D10VG1 | 405nm | ¢4.5mm | <5.0mw | 0.1mrad | ¢5mm(@10m) | Optical Glass | ¢10x35mm |
VB405D10VG2 | 405nm | ¢5.0mm | <7.0mw | 0.2mrad | ¢4x8mm(@10m) | Optical Glass | ¢12x40mm |
VB405D20VG1 | 405nm | ¢4.5mm | <10.0mw | 0.1mrad | ¢8mm(@20m) | Optical Glass | ¢12x40mm |
VB405D20VG2 | 405nm | ¢5.0mm | <14.0mw | 0.2mrad | ¢6x12mm(@20m) | Optical Glass | ¢12x40mm |
VB405D40VG1 | 405nm | ¢4.5mm | <20.0mw | 0.1mrad | ¢8mm(@20m) | Optical Glass | ¢14x50mm |
VB405D40VG2 | 405nm | ¢5.0mm | <28.0mw | 0.2mrad | ¢6x12mm(@20m) | Optical Glass | ¢14x50mm |
VB405D60VG1 | 405nm | ¢4.5mm | <30.0mw | 0.1mrad | ¢8mm(@20m) | Optical Glass | ¢14x50mm |
VB405D60VG2 | 405nm | ¢5.0mm | <40.0mw | 0.2mrad | ¢6x12mm(@20m) | Optical Glass | ¢14x50mm |
VB405D100VG1 | 405nm | ¢4.5mm | <50.0mw | 0.1mrad | ¢8mm(@20m) | Optical Glass | ¢16x60mm |
VB405D100VG2 | 405nm | ¢5.0mm | <70.0mw | 0.2mrad | ¢6x12mm(@20m) | Optical Glass | ¢16x60mm |
QC Flow
1 Professional Power Meter for double check
2 Qualified professional staff for the beam size/line thickness testing
3 Strictly surface Inspection before load to the warehouse.
Product pictures of diode pumped laser module
