Gold supplier china 3mW ~ 70mW overhead projector
- 100000 Piece / Pieces per Month
- XI AN
- Credit Card
- Mini Laser Module with APC 4x8mm
- Laser Module, 15x60mm Size 405nm-850nm 8um-110um Microbeam Laser Diode Module for Laser Positioning & Pointing
- Mini laser module for laser alignment tools
- 1-5mw 520nm Low Consumption Mini Laser Diode Module 4x8mm
- 1-5mw Mini Infrared Laser Module for Measure Tools and Medical Treatment Instrument
- Mini laser module for bar code scan instrument
Product Details
Place of Origin: | Shanxi, China | Brand Name: | ELITE | Model Number: | ELM53-05A ELM63-05A ELM65-80A etc. |
Product Description
Gold supplier china 3mW ~ 70mW overhead projector
Product descriptions of overhead projector:
- Application: cutting stone, wood etc.
- Supply Voltage: 3-250VDC
- Operating Temperature: -10°C ~ 50°C
- Beam type: line
- Certificated: FDA IEC SGS ISO9001-2008
- wavelength: 532nm,635 nm,650nm.
- LD power: 5mw-130mw
- Fan Angle: 90° or 110°
- output power: 3mW ~ 70mW
- laser line color: green,red
- optical lens: Optical glass
- laser type: laser aligner
- CDRH class: class IIIa ,Class IIIb
Key Features:
1) Wide Temp. Operating
2) High brightness
3) High Reliability
4) Long Lifetime
5) Feasible Solutions
Application:
Light Source of Below Devices
1) Stone Cutting Devices
2) Woods Cutting Devices
3) Cloth Cutting Devices
4) Other Cutting Devices
Laser line projector Specifications:
Dimensions: | A series ¢26*110mm ¢ 16*70mm |
B series ¢ 40*180mm ¢ 50*210mm | |
Wavelength: | 532nm,635 nm,650nm |
LD power: | 5 mw ~ 130mw |
Fan Angle: | 110°or 90° |
Line Thickness:: | 1 mm (@3 m), 2 mm (@5 m) |
Line Length: | 1: 3.0 or 1: 2.0 (Distance: Length) |
Operating Voltage: | 5VDC or 90 ~ 250 VAC (50/60Hz) |
Operating Current: | 50 mA ~ 250 mA |
Operating Temp: | - 10°C ~ 50°C |
Storage Temp: | - 40°C ~ 80°C |
CDRH Class | Class IIIa, Class IIIb |
Optical Lens: | Optical Glass |
Note:
ELMXX-OOA was defined as the separated power supply and the laser head
ELMXX-OOB was defined as the combined power supply and the laser head.
Model | Wavelength | Output Power | Line Thickness | Fan Angle | Operating Voltage | Dimension |
ELM53-05A | 532nm | 3mw | <2.0mm(@3m) | 90° | ||
ELM53-10A | 532nm | 7mw | <3.0mm(@5m) | 90° | 3VDC | |
ELM53-20A | 532nm | 14mw | <4.0mm(@8m) | 90° | ||
ELM63-05A | 635nm | 3mw | <1.5mm(@3m) | 110° | ||
ELM63-10A | 635nm | 6mw | <2.0mm(@5m) | 110° | ¢ 16×70mm | |
ELM63-20A | 635nm | 12mw | <3.0mm(@8m) | 110° | ¢26×110mm | |
ELM63-30A | 635nm | 18mw | <4.0mm(@10m) | 110° | 5VDC | |
ELM65-60A | 660nm | 20mw | <1.5mm(@3m) | 110° | ||
ELM65-80A | 660nm | 35mw | <2.0mm(@5m) | 110° | ||
ELM65-100A | 660nm | 50mw | <3.0mm(@8m) | 110° | ||
ELM65-130A | 660nm | 70mw | <4.0mm(@10m) | 110° | ||
ELM53-05B | 532nm | 3mw | <2.0mm(@3m) | 90° | ||
ELM53-10B | 532nm | 7mw | <3.0mm(@5m) | 90° | ||
ELM53-20B | 532nm | 14mw | <4.0mm(@8m) | 90° | ||
ELM63-05B | 635nm | 3mw | <1.5mm(@3m) | 110° | ||
ELM63-10B | 635nm | 6mw | <2.0mm(@5m) | 110° | ¢40×180mm | |
ELM63-20B | 635nm | 12mw | <3.0mm(@8m) | 110° | 90-250VAC | ¢50×210mm |
ELM63-30B | 635nm | 18mw | <4.0mm(@10m) | 110° | ||
ELM65-60B | 660nm | 20mw | <1.5mm(@3m) | 110° | ||
ELM65-80B | 660nm | 35mw | <2.0mm(@5m) | 110° | ||
ELM65-100B | 660nm | 50mw | <3.0mm(@8m) | 110° | ||
ELM65-130B | 660nm | 70mw | <3.0mm(@8m) | 110° |
Product pictures of overhead projector:
NOTE:
The specification of output power and fan angle is adjustable according to customer’s requirement.
Product Warranty, Shipping Method and Payment Method
Warranty:
we offer 12 months limited warranty for our products. Damage due to misuse, Ill treatment and unauthorized modifications and repairs are not covered by our warranty.
Payment Method:
we usually accept the payment methods include Paypal, Bank Transfer, Western Union, and MoneyGram. Buyer can choose which payment ways that you accept. Paypal is most useful and safe, please don’t refuse Paypal fee when you choose Paypal.
Shipping Method:
We provide comprehensive shipping methods, for small quantity orders we ship by DHL Air-Express, or EMS/TNT Express service, it is safe and fast. For large quantity orders we can ship by Air transportation or sea transportation, also we can ship order to buyer’s cargo agent in China. We quoted prices are EXW price, don’t include shipping cost
