Wide work temperature China alunimium anodized/brass diode laser,green laser module
Product descriptions of green laser module :
Key Feature |
Application |
1. High quality |
1. Industrial Instruments and Equipments |
2. High Stability |
2. Wild Explore Instruments |
3. High reliability |
3. Military Instruments and Equipments |
4. APC driving circuit |
4. Medical Instruments |
5. Low cost |
5. Surveying Instruments |
6. Long Life |
6. Bar Scan |
Which including the Industrial Laser Diode Modules ,Mini Laser Diode Module,High Stability Laser Module, etc.
Part 1: Industrial Laser Diode Modules
Elite Industrial Laser Diode Modules use high quality laser diode with special designed collimating lens and high stable driven circuit (APC). The characteristics are high reliability, long life span (>10000hrs), and high stability. It’s mainly applied in all kinds of industrial instruments and equipments, field detecting, surveying instruments, military instruments and equipments; gun laser sight, medical apparatus, laser appliance and various of laser apparatus, etc.
Key Feature: |
Application: |
High Quality |
Industrial Instruments and Equipments |
High Stability |
Wild Explore Instruments |
High Reliability |
Military Instruments and Equipments |
APC Driving circuit |
Medical Instruments |
Low Cost |
Surveying Instruments |
Long Life |
Bar Scan |
Items |
Specifications |
||||||||
Spectral Range |
Violet |
Blue |
Red |
Infrared |
|||||
Wavelength |
405nm |
450nm |
635nm |
650nm |
780nm |
808nm |
830nm |
850nm |
980nm |
LD power(mW) |
5- 50 |
5-60 |
5~180 |
5~150 |
5~200 |
50~5000 |
5-100 |
5~100 |
20~5000 |
Operating Current |
25~5000mA |
||||||||
Input Voltage |
2.6~5.5VDC |
||||||||
Operating Temp. |
-10°C ~ 50°C |
||||||||
Storage Temp. |
-40°C ~ 80°C |
||||||||
Power Stability |
> 98% (@2.7 ~ 5.5VDC) |
||||||||
> 95% (@-10°C ~ 50°C) | |||||||||
MTTF |
>10000 Hrs. |
||||||||
Circuit Protection |
Static, Surge, and Reverse Polarity Protected |
||||||||
Case Material |
Brass or Aluminum |
||||||||
Beam Pattern |
Dot |
||||||||
Note:
1, The Dot series laser diode module is customized product with different plastic and glass lens. Thus the laser shape could be an ellipse or circle with various divergence, beam size and aperture. The output power is adjustable according to customers’ requirements.
2, Dimensions are customized according to customer’s needs except the ones list.
3, More models could be offered such as EL65D05IGX, EL65D05IG6,EL65D05IG7,EL65D05IG10,EL65D05IG15, etc. Elite is continually developing new models and launching to me
Part 2: Mini Laser Diode Module
Mini laser diode module, small dimension and with low power consumption, particularly suited for built-in miniature devices and tools, which could enable the laser tools and equipments miniaturized. Mini laser diode module is mainly applied in gun laser sighting, bar code scanning, etc.
Key Feature
1. Small dimension
2. Low Consumption
3. Low cost
Application:
- Gun Laser Sight
- Laser Alignment
- Bar Scan
Part 3: High Stability Laser Module
405nm, 445nm, 520nm Laser Diode Module
Elite could provide high quality 405nm,445nm,520nm laser diode module. Except the models listed below, several more options are available. Elite could also do customized new Blue Violet & Green Laser Diode Module.
405nm (Violet) 5mw ~ 120mw Dot & Line Laser Diode Module
445nm (Blue) 5mw ~ 200mw Dot & Line Laser Diode Module
520nm (Green) 5mw ~ 80mw Dot & Line Laser Diode Module
QC Flow:
1 Professional Power Meter for double check
2 Qualified professional staff for the beam size/line thickness testing
3 Strictly surface Inspection before load to the warehouse.
Sent Us Inquiry Now and Pls mention the following points:
1 Wavelength
2 Output Powder
3 Housing Dimension
4 Work distance
5 Beam size
Product pictures of green laser module :
