80-160 ton converter SLIDE GATE STOPPING slag and INFRARED system
The old converter finished the slide gate stopping slag’s application through tapping modification. Stopping slag with slide gate is successful which can reduce the cost of production. Slag tapping amount can be controlled around 40 mm, which provides requirement for the production of variety of steel.
Technical Features:
1.Higher than 98% slag stopping rate, effectively reducing the average slag thickness of ladle, slag thickness≤40mm(no synthetic slag)
2. Simple and rational structure, safe and reliable use, simple operation and convenient repair and replacement
3.Device closing speed≤1 second;
4.The skateboard replace time≤15 mins/time(no inner nozzle brick,No manipulator);
5.The skateboard and outside nozzle average service life ≥12 times(no flow control)
6.Inner nozzle average service life ≥40 times (synchronize replaced with tapping hole);average service life ≥24 times(replace alone);
Model |
Unit |
ZHDZ-150B-00 |
ZHDZ-300B-00 |
External dimensions(A×B×H) |
mm |
1470×1200×410 |
1780×1500×430 |
Skateboard dimensions |
mm |
600×310×50/75 |
700×350×50/80 |
Tapping hole dimension(D) |
mm |
120/150 |
140/180 |
|
Oil cylinder Stroke (L) |
mm |
230 |
280 |
Spring quantity |
piece |
14 |
16 |
Spring Specification |
mm |
61×81×13 |
61×81×13 |
Skateboard replace form |
|
off-kine replace |
off-kine replace |
Converter Size |
t |
60~150 |
150~300 |
