Q235B Commercial Heavy Duty Scaffolding Kwikstage Standard
Kwikstage Standard
Verticals form the support or the uprights and are made from Standard Scaffold Tubes of 48.3 x 4 mm thick. They have a series of "V" pressed welded at nominal 500 mm on the tube to provide a location for ledger and transoms. Products are manufactured to Australian Standard AS1576.
KwikStage Steel Scaffolding is a heavy duty modular scaffolding system which is the most common method of access today for work at heights.
KWIKSTAGE STANDARD
ITEM NO. |
MATERIAL |
LENGTH |
FINISH |
STANDARD |
ADKS3000 |
Q235, 48.3x4mm |
3.0m |
Painted |
AS/NZS 1576 |
ADKS2500 |
Q235, 48.3x4mm |
2.5m |
Painted |
AS/NZS 1576 |
ADKS2000 |
Q235, 48.3x4mm |
2.0m |
Painted |
AS/NZS 1576 |
ADKS1500 |
Q235, 48.3x4mm |
1.5m |
Painted |
AS/NZS 1576 |
ADKS1000 |
Q235, 48.3x4mm |
1.0m |
Painted |
AS/NZS 1576 |
ADKS0500 |
Q235, 48.3x4mm |
0.5m |
Painted |
AS/NZS 1576 |
KWIKSTAGE LEDGER
ITEM NO. |
MATERIAL |
LENGTH |
FINISH |
STANDARD |
ADKL24 |
Q235, 48.3x3.2mm |
2.4m |
Painted |
AS/NZS 1576 |
ADKL18 |
Q235, 48.3x3.2mm |
1.8m |
Painted |
AS/NZS 1576 |
ADKL12 |
Q235, 48.3x3.2mm |
1.2m |
Painted |
AS/NZS 1576 |
ADKL08 |
Q235, 48.3x3.2mm |
0.8m |
Painted |
AS/NZS 1576 |
ADKL07 |
Q235, 48.3x3.2mm |
0.7m |
Painted |
AS/NZS 1576 |
ADKL05 |
Q235, 48.3x3.2mm |
0.5m |
Painted |
AS/NZS 1576 |
KWIKSTAGE TRANSOM
ITEM NO. |
MATERIAL |
LENGTH |
FINISH |
STANDARD |
ADKT24 |
Q235, 50x50x5mm |
2.4M |
Painted |
AS/NZS 1576 |
ADKT18 |
Q235, 50x50x5mm |
1.8M |
Painted |
AS/NZS 1576 |
ADKT12 |
Q235, 50x50x5mm |
1.2M |
Painted |
AS/NZS 1576 |
ADKT10 |
Q235, 50x50x5mm |
1.0M |
Painted |
AS/NZS 1576 |
ADKT08 |
Q235, 50x50x5mm |
0.8M |
Painted |
AS/NZS 1576 |
ADKT07 |
Q235, 50x50x5mm |
0.7M |
Painted |
AS/NZS 1576 |
ADKT05 |
Q235, 50x50x5mm |
0.5M |
Painted |
AS/NZS 1576 |
KWIKSTAGE SCAFFOLDING ACCESSORIES:
Hop up Bracket(One Board)
Hop up Bracket(Two Board)
Hop up Bracket(Three Board)
Kwikstage Base Screw Jack
Wall Tie
Mesh Pallet
Stair Case
Mesh Rack
Gal Stillage
Toe Board Bracket
Ladder Access Transom
End Toe Board Bracket
Base Plate
