Industrial painted steel scaffolding hop up bracket 1 2 3 board
Hop up bracket fit into the "V" pressing of the standard which is nearest to the wall. The 2 have holes into which tie bar pins are attached. They are used to provide cantilevered platform on the inside of the scaffold nearest the wall.
Hop-Up Brackets enable work to take place away from the main scaffold run, they are available in 1,2 and 3 board widths. Hop-Up Brackets are also very useful if the building is to be rendered as they can be in place on construction but removed for the rendering giving the workers easy access, they should be used with Tie Bars.
ADVANTAGES:
a ) Durability: the hop up bracket is made of tough material and provides long-term benefits.
b ) Lower maintenance costs: It does not require costly maintenance.
c ) No loose fittings: the wedgelock system without any screws or nuts
d ) Labor saving: An excellent feature of this scaffold is that it can be erected and dismantled easily and fast.
KWIKSTAGE STANDARD
ITEM NO. |
MATERIAL |
LENGTH |
FINISH |
STANDARD |
ADKS3000 |
Q235, 48.3x4mm |
3.0m |
Painted |
AS/NZS 1576 |
ADKS2500 |
Q235, 48.3x4mm |
2.5m |
Painted |
AS/NZS 1576 |
ADKS2000 |
Q235, 48.3x4mm |
2.0m |
Painted |
AS/NZS 1576 |
ADKS1500 |
Q235, 48.3x4mm |
1.5m |
Painted |
AS/NZS 1576 |
ADKS1000 |
Q235, 48.3x4mm |
1.0m |
Painted |
AS/NZS 1576 |
ADKS0500 |
Q235, 48.3x4mm |
0.5m |
Painted |
AS/NZS 1576 |
KWIKSTAGE LEDGER
ITEM NO. |
MATERIAL |
LENGTH |
FINISH |
STANDARD |
ADKL24 |
Q235, 48.3x3.2mm |
2.4m |
Painted |
AS/NZS 1576 |
ADKL18 |
Q235, 48.3x3.2mm |
1.8m |
Painted |
AS/NZS 1576 |
ADKL12 |
Q235, 48.3x3.2mm |
1.2m |
Painted |
AS/NZS 1576 |
ADKL08 |
Q235, 48.3x3.2mm |
0.8m |
Painted |
AS/NZS 1576 |
ADKL07 |
Q235, 48.3x3.2mm |
0.7m |
Painted |
AS/NZS 1576 |
ADKL05 |
Q235, 48.3x3.2mm |
0.5m |
Painted |
AS/NZS 1576 |
KWIKSTAGE TRANSOM
ITEM NO. |
MATERIAL |
LENGTH |
FINISH |
STANDARD |
ADKT24 |
Q235, 50x50x5mm |
2.4M |
Painted |
AS/NZS 1576 |
ADKT18 |
Q235, 50x50x5mm |
1.8M |
Painted |
AS/NZS 1576 |
ADKT12 |
Q235, 50x50x5mm |
1.2M |
Painted |
AS/NZS 1576 |
ADKT10 |
Q235, 50x50x5mm |
1.0M |
Painted |
AS/NZS 1576 |
ADKT08 |
Q235, 50x50x5mm |
0.8M |
Painted |
AS/NZS 1576 |
ADKT07 |
Q235, 50x50x5mm |
0.7M |
Painted |
AS/NZS 1576 |
ADKT05 |
Q235, 50x50x5mm |
0.5M |
Painted |
AS/NZS 1576 |
KWIKSTAGE SCAFFOLDING ACCESSORIES:
Hop up Bracket(One Board)
Hop up Bracket(Two Board)
Hop up Bracket(Three Board)
Kwikstage Base Screw Jack
Wall Tie
Mesh Pallet
Stair Case
Mesh Rack
Gal Stillage
Toe Board Bracket
Ladder Access Transom
End Toe Board Bracket
Base Plate
