ASTM B265 Grade 5 Titanium Plate for Industry Use

Name: ASTM B265 Grade 5 Titanium Plate for Industry Use
Brand: dongfu
SKU: 124649309
Availability: InStock

US$ 20 - 50 MOQ: 50 Kilograms

Key Specifications

Place of Origin:

Jiangsu, China

Application:

industry

Thickness:

0.5~1.0mm

Zhangjiagang City Dongfu Titanium Metal Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai for gr5 titanium plate

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Application industry

Thickness 0.5~1.0mm

Width 300~1000mm

Length 800~3000mm

Technique Cold Rolled

Grade GR5

Ti (Min) 99.6%

Brand Name dongfu

1. Titanium Plate Product Description:

1>Ti (Min): 99.6%
2>Technique:hot roll
3>Size:(0.3-60)*(>=400)*(>=1000 )mm
4>Surface:abrasive cleaning

Production Name	titanium sheet
Grade	Gr1Gr2Gr3
Size	0.3-60*400-30001000-4000mm
Standard	ASTM B265 ASTM F67 AMS 4911
Supply status	M
Application	chemical industry, Metallurgy, marine engineering. military industry , medical industry, Electroplating industry, ,precision instrument,sport ,car
Feature	High corrosion resistance,low density,good thermal stability
Packing	Wooden case as outside,plastic bag as inside,or standard export packaging
MOQ	20kg
Payment Terms	L/C T/T
Delivery time	10—30days according to the quantity and process of the product
Quality Test	Strict test is indispensable,because we must insure our clients get the best product

1) room temperature mechanical properties

Grade	Supply State	Titanium sheet Thickness(mm)	Tensile strength Rm/MPa(>=)	Provision of non-proportional Extension strength Rp0.2/MPa	Break Elongation aA/%(>=)
Gr1	M	0.3-25.0	240	140-310	30
Gr2	M	0.3-25.0	400	275-450	25
Gr3	M	0.3-25.0	500	380-550	20
Gr4	M	0.3-25.0	580	485-655	20
Gr5	M	0.8-2.0 2.0-5.0 5.0-10.0 10.0-25.0	895	>830	12 10 10 8
Gr6	M	0.8-1.5 >1.6-2.0 >2.0-5.0 >5.0-10.	735-930	>685	20 15 12 12
Gr7	M	0.8-10	400	275-450	20
Gr9	M	0.5-2.0 2.0-4.0 4.0-10.0	590-735	---	25 20 15
TC4ELI (Gr23)	M	0.8-25.0	860	>795	10
