ASTM F136 Titanium Sheets/Gr1 Cold rolled titanium sheet
Size(mm):
Cold Rolled(thinkness:0.3~4.0mm Width:400~1000mm Length:1000~3000)
Hot Rolled(thinkness:4.1~60.0mm Width:400~3000mm Length:1000~4000)
Standard:ASTM B265,AMS4911,ASTM F67,ASTM F136
Grade:GR1.GR2,GR3,GR5,GR7,GR9,GR12…
MOQ:5KG Sample is available.
Package:plywood case
Delivery Time: 3 to 15 days,or as your quantity.
Payment: T/T or L/C at sight, Western Union , Paypal
Supply ablity :100 tons/month
Port of shipment :tianjin /shenzhen /shanghai
Specifications
Material: GR1,GR2.GR4,GR5
Standard: ASTM B265,AMS4911,ASTM F67,ASTM F136 Thickness:0.5mm-5mm;
Width:200mm-1500mm
Length:500mm-6000mm
Customized is ok for us.
Composition
Element |
Composition,% |
||||||||
Gr1 |
Gr2 |
Gr3 |
Gr4 |
Gr5 |
Gr7 |
Gr9 |
Gr11 |
Gr12 |
|
N max |
0.03 |
0.03 |
0.05 |
0.05 |
0.05 |
0.03 |
0.03 |
0.03 |
0.03 |
C max |
0.08 |
0.08 |
0.08 |
0.08 |
0.08 |
0.08 |
0.08 |
0.08 |
0.08 |
H max |
0.05 |
0.015 |
0.015 |
0.015 |
0.015 |
0.015 |
0.015 |
0.015 |
0.015 |
Fe max |
0.2 |
0.3 |
0.3 |
0.5 |
0.4 |
0.5 |
0.25 |
0.2 |
0.3 |
O max |
0.18 |
0.25 |
0.35 |
0.4 |
0.2 |
0.25 |
0.15 |
0.18 |
0.25 |
Al |
|
|
|
|
5.5-6.75 |
|
2.5-3.5 |
|
|
V |
|
|
|
|
3.5-4.5 |
|
2.0-3.0 |
|
|
Pd |
|
|
|
|
|
0.12-0.25 |
|
|
|
Feature
Rare metal titanium ,with low density ,high specific strength and srrong corrosion resistance,has become a new engineeringmaterial widely used in aviation ,aerospace ,navigation ,petroleum,chemical industry,metallurgy ,electroplating,vacuum coating ,medical industry ,sport and other industries .
Description about Titanium grades
Titanium Grade 1-4 is pure Titanium, the other grades are alloys. Pure Titanium is used due to its high corrosion resistance, the alloys because of the extremely high strength to weight ratio.
l Grade 1. Pure Titanium, relatively low strength and high ductility.
l Grade 2. The pure titanium most used. The best combination of strength, ductility and weldability.
l Grade 3. High strength Titanium, used for Matrix-plates in shell and tube heat exchangers.
l Grade 5. The most manufactured titanium alloy. Excedingly high strength. High heat resistance.
l Grade 7. Superior corrosion resistance in reducing and oxidizing environments.
l Grade 9. Very high strength and corrosion resistance..
l Grade 12. Better heat resistance than pure Titanium. Applications as for Grade 7 and Grade 11.
l Grade 23. Titanium-6Aluminum-4Vanadium ELI (Extra Low Interstitial) Alloy for surgical implant Applications
.
