Titanium price per kg ASTM B265 titanium sheet
tem |
titanium sheet /titanium plate |
Grade |
GR1, GR2, GR3, GR4, GR5, GR7, GR9, GR12, 6AL4V Eli,Gr23 |
Standard |
ASTM B265,ASTM F67, ASTM F136, ISO5832-2, ISO5832-3, AMS 4911,AMS 4905,AMS 4907,MIL-T-9046 |
Specification |
Thickness (0.5—4.0)× Width(30—2500)×≤6000mm Thickness (4.1—100.0)× Width(50—3000)×≤10000mm
|
Technics |
Hot rolling or cold rolling |
Surface |
Bright,Polished, Pickling, Acid cleaning,Sandblasting |
Payment |
T/T, L/C at sight, D/A,D/A, Western Union or as your inquiry |
Certificate |
ISO 9001:2008, EN10204 3.2 ,SGS, UKAS, The third test report |
Supply ability |
10 Tons Per month |
Delivery |
Within 5~20 days |
Mechanical property
Grade |
condition |
Mechanical property
|
||||
|
Tensile strength Rm/Mpa |
Yield strength Rp0.2/Mpa |
Elongation A% |
Erichsen number mm |
|||
Gr1 |
M |
>=240 |
>=140 |
>=55 |
>=9.5 |
|
Tolerance
Thickness |
Tolerance of thickness |
Tolerance of width |
Tolerance of length |
0.5~0.8 |
±0.07 |
+10 0 |
+15 0 |
Description about Titanium grades
Titanium Grade 1-4 is pure Titanium, the other grades are alloys. Pure Titanium is used due to its high corrosion resistance, the alloys because of the extremely high strength to weight ratio.
l Grade 1. Pure Titanium, relatively low strength and high ductility.
l Grade 2. The pure titanium most used. The best combination of strength, ductility and weldability.
l Grade 3. High strength Titanium, used for Matrix-plates in shell and tube heat exchangers.
l Grade 5. The most manufactured titanium alloy. Excedingly high strength. High heat resistance.
l Grade 7. Superior corrosion resistance in reducing and oxidizing environments.
l Grade 9. Very high strength and corrosion resistance..
l Grade 12. Better heat resistance than pure Titanium. Applications as for Grade 7 and Grade 11.
l Grade 23. Titanium-6Aluminum-4Vanadium ELI (Extra Low Interstitial) Alloy for surgical implant Applications.
