Brushless Generator Single Phase Auto Alternator Voltage Regulator AVR EA440 :
Features
- < ±1% Regulation
- Can Be Use In Parallel Operation
- Adjustable DIP, TRIM & DROOP Function
- Under Frequency Roll Off Protection
- Sensing Voltage Loss Protection
- Under Frequency LED Indicator
- Soft Start Voltage Ramping
EA440-T Technical specification
Technical specification | |
Sensing input | |
voltage |
190 ~ 264 VAC, 1 phase 2 wire |
frequency |
50/60Hz Single Phase |
output | |
voltage |
Max. 90 VDC at 207 VAC |
Current |
Continuous 4A, Intermittent 10 A for 10 sec |
resistance |
15 ohms min |
regulation |
+/- 1.0% (with 4% engine governing) |
Thermal drift |
0.04% per °C change in AVR ambient |
Under frequency protection | |
Set point |
95% Hz |
Unit power dissipation |
12 watts maximum |
ANALOGUE INPUT |
|
Maximum input |
+/- 5V dc |
Sensitivity |
1v for 5% Generator Volts (adjustable) |
Input resistance |
1k ohm |
QUADRATURE DROOP INPUT | |
Max. sensitivity |
0.07 A for 5% droop 0PF |
Max. input |
0.33 A |
The following are our products:
1. CF Brushless AVR: CF-8A, CF-12A, CF-15A, GAVR-15A, SAVRH-75A, SAVRH-PCB, SAVRL-75A, SAVRL-PCB.
2. Stamford AVR: AS440, MX321, MX321-A, MX341,MX341-A, SX440, SX440-A, SX440-T, SX460, SX460-A.
3. Leroysomer AVR: R230, R438,R448, R449, SSAYEC432.
4. Marathon AVR: SE350.
5. Brush AVR: DX-2E, DX-5E, DX-7E, DX-8E, DX-11E, DX-05A.
6. Engine Governor: 3036453, 34008326, EFC3044196, ESD5111, ESD5500E.
7. Controller: CTR101, CTR168, DSE501K, DSE5110
For more detail informations, would you please visit our website:
Have a nice day. Thanks.
Packaging: Standard Carton Packing
Payment Terms:
1.We accept West Union, T/T, MoneyGram, L/C,D/P,D/A, Escrow, Cash.
2.All major Credit cards are accepted through secure payment processor ESCROW.
Shipment Terms:
1. We Ship to Worldwide, except APO/FPO
2. Orders processed timely after showing bank transfer.
3. We only ship to confirmed order addresses. Your order address MUST MATCH your address.
1.Founded in 2005,with full experience of 10 years in manufacturing generator spare parts.
2.Started export since the year of 2008,with quick response to serve the oversea customers
3.Have already passed the strict quality inspection of ISO9001:2000 quality management system
4.Strong R&D Team to design and test products
5.Professional designers and technicians to provide technical assitance
6.Strict quality control process with strict standards
7.Strong installation consulting support
8.Quick after-sale technical advice and guidance
