ZY-261B 105.Furniture Hinge (Half-overlay)

ZY-261B 105^.(Half-overlay)

H=height of mounting plate

D=required door overlay

K=drilling distance from the edge of door to the edge of the hole

A=gap between door and side board

Two sections strength hinge

Opening degree: 105^.

Thickness of hinge cup:11.5mm

Diameter of hinge cup:35mm

Dimension of door (K):3-7mm

Range for door thickness:14-24mm

(Hinge cup types)

China Famous Jieyang Hardware Association

Choose Us To Cooperate

-We Are More Than Twenty Years In This Line

-All The Products Is Passed By 24 Hours Salt Spray Gurantee

-Everytime We Seriously Use Good Material

We Take Part In CIFF Every Year

Guangdong Jieyang Zhihui hardware factory is one professional company specialize in the research, manufacturer and sales of “Zhiyi” brand lead rail, bolt and other furniture parts.

The factory has advanced production equipment, high-quality professional and technical personnel, strict and scientific management system for the development of custom furniture factory rail services to various models. Welcome to visit our community!
Customer Service Hotline (Tel): +86-0663-3831123 Fax :86 -0663-3831345

The contact:Satina Yang Mobile:86-13927001680
