Specifications
Fruits and Vegetables washing machineair bubble type and brush type.
Fruit washing and grading line
Flow chart of the fruit washing line
Conveyer → washing→ rinsing→ waxing→ heating and drying→ conveyer→ grading
Main parts of the line:
No. | Name | Quantity |
1 | Cleaning machine and loading part | 1 set |
2 | Rising and waxing portion | 1 set |
3 | Heating and drying portion | 1 set |
4 | Automatic feeding for grading machine | 1 set |
5 | Conveying belt | 1 set |
6 | Single-lane Electronic fruit grading machine | 1 set |
Main parts of the fruit washing line
A. Hydraulic loader structure
Normal Size: 900*800*650mm and design according work capacity
B. Washing and loading part
Structure: stainless steel water tank, grading and elevating platform, and high pressure water pump.
After washing in the stainless steel water tank, the fruits will be elevated to the straight selection platform, and the plastic roll will move forward and rotate, which will make it easier for the inferior fruits to be selected out. (Fruit elevator: 2900 * 900 * 1150mm)
B. Rinsing and waxing part
Structure: brush, rinsing outlet, timer, wax spraying outlet.
During the conveying process, the brushes will clean out the water on the fruit, and they are also used to brighten the fruit. Four cooling fans are installed in the middle of the brushes for drying the fruits
During the second half of conveyance, timer is used to control electromagnetic wax spraying outlet, where edible wax is sprayed. The interval time and wax spraying time can be set freely. After spraying, the rotated brushes will make the wax sprayed homogeneously spread on the fruit.
C. Heating and drying part
Heated by natural gas burner and intelligent temperature controller is installed. The temperature control can be set to be automatic and manually edited.
The temperature in the drying tunnel is from low to high. And the wind in the tunnel is circularly blown. Centrifugal blower is employed to make the inside air to be converted.
D. Automatic loader for grading machine
Use conveyor belt and rubber-tired to load fruit to the fruit grading machine conveyor belt.
E. Single-lane, double lane, four lane, six lane, eight lane Electronic fruit grading machine according to the work capacity, can design the different machine line.
Speed: 20000-21000pcs/hour
Electronic controlling system: Siemens elements text display, CPU, Weighing module, weighing sensor
Grade: 9 grades,9 compartments
