Large Stainless Steel Balls

Name: Large Stainless Steel Balls
Brand: WANSTEEL
SKU: 124577709
Availability: InStock

US$ 600 - 1,000 MOQ: 1 Ton

Key Specifications

Standard:

AISI, ASTM, DIN, GB, JIS

Grade:

400 Series

Diameter:

Shandong Wan Steel Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Standard AISI, ASTM, DIN, GB, JIS

Grade 400 Series

Diameter 10

Application bearing/mining

Certification Other, BV/ISO

Hardness HRC55-65

Place of Origin Shandong, China

Brand Name WANSTEEL

Specifications

large stainless steel balls:
1) Materials: AISI316
2) Precision grades: G10-G60
3) Diameters: 2MM - 70mm

Stainless Steel Ball for Bearing:

1) Materials: GB0Cr17Ni11Mo2, AISI316, SUS316, DINX5CrNiMo1712

2) Precision grades: G10-G60

3) Diameters: 2MM - 70mm
4) Standards: ISO9001:2008

We are the most professional stainless steel ball manufacturer in China

We have been the largest stainless steel ball factory in Northeast of China.

1 ) Material Comparison List

2) Products information

NAME	stainless steel balls
Diameters	2mm-70mm
Materials	GB0Cr17Ni11Mo2, AISI316, SUS316, DINX5CrNiMo1712
Precision grades:	AFBMA STANDARD 10-2001-USA G10-G60
average hardness index	135-200 HV10
Mechanical properties:
critical tensile strenght	63.2 kgf/mm²
compression strenght	31.7 kgf/mm²
modulus of elasticity	19.693 kgf/mm²
specific weight	8.04 kgf/mm²
Application	the most common applications includes their use in the chemical, paper and textile valves, pumps and bearings.
Quality Standard	ISO9001:2008
Characteristics and advantages	all balls are annealed and passivated they are austenitic stainless steels with features similar to AISI302/304/304L series, but they are more anti-magnetic and, above all, the addition of molybdenum offers greater chemical resistance, particularly in sulphuric acid concentration.
